Suitable for hrc30-52 metal workpiece, the use of universal good
altin coating, the workpiece surface smoothness is better, the
processing material is more versatile, it is recommended to use
high rigidity, high precision handle and barrel clip, comprehensive
runout control within 0.005mm.Smooth chip removal design, enhance
resistance to damage, improve the finish of processing surface,
Selects fine grain quality bar, processing imported five axis tool
grinding machine, cutting tool inspection standard strictly, to
ensure the consistency of the cutter size and beating altin nano
coating, resistant to high temperature wear resistance, hardness
and toughness of the notification with coating, suitable for 63 °
hard steel, hardened steel, aluminum, copper materials, under the
condition of the bits ensure the space, the big core diameter
design, greatly enhance the tool rigidity and vibration resistance,
reduce the cutting knife, prolong service life.Through the
passivation technology, the tool adhesion particles are completely
removed, the blade is passivated, the processing of high hardness
material is more easy to use, anti-breakage edge, extending the
service life of the tool.
1.Original raw micro grain material, high hardness and T.R.S.
a, Material: tungsten carbide
b, TRS: >3600 N/mm2
c, HRA: 91.8-92.4, HRC:45/55/60/65
d, Grain size: 0.2-0.6μm
e, Helix angle: 30°-45 °
Diameter of cutting edge: 0.2-0.9mm; 1-20mm
Size: Diameter 1.0mm-20mm standard and non-standard.
Cutting Form: Square,Ball nose, Corner Radius, Taper Flute, etc.
Type of flute: 2/3/4
2.Other products
Drills,reamer, tool holders, ER collet, boring cutters, carbide
inserts, cutter heads,etc.
3.Application and usage
Suitable for Copper, Cast Iron, Carbon steel, Tool steel, Mould
steel, Die steel, Stainless steel, Plastic, Arcylic, aluminum alloy
steel, non ferrous alloy etc.
4. Super coating:
| Item | AlTiN | TiAiN | TiSiN | nAcO |
| Hardness(HV) | 3200 | 2800 | 3600 | 42(GPA) |
| Thickness(UM) | 2.5-3 | 2.5-3 | 3 | 3 |
| Oxidation Temp( ° ) | 900 | 800 | 1000 | 1200 |
| Friction | 0.3 | 0.3 | 0.45 | 0.4 |
| Color | Black | Violet | Copper | Blue |
improve tool life, reduce the coefficient of friction.
Our advantages:
1.Solid carbide lasting long life in hardened steels, Grain size
carbide, high toughness,high-wearing feature.
2.Non-standard can be customized according to customer's
requirements
3.We have produce ability to satisfy your orders,another
manufacturing bases will becompeleted in the near month.
4.12 years professional experience.
5. Strict quality checking.
