ABB TPS52-F32 Two Hole Turbine Casing Design 51000 Casing In Turbine
Description:
As to ABB TPS52-F32 Two Hole Turbine Casing Design 51000 Casing In
Turbine, the shell body com–
prises a first end, a second end and a central region, wherein the
shell body includes an inner cavity
through which the inner cavity gradually shrinks from a first
larger section at and / or in the regions of
the first end and the second end toward the central region to a
second smaller section. The turbine casing
may include a fluid flow limiting device, which is arranged to
limit the fluid velocity, direction or position in the
turbine casing.
Specifications:
| Brand | ABB |
| Type | TPS52-F32 |
| Name | Turbine Casing |
| P/N | 51000 |
| MOQ | 1 |
| Price | Negotiable |
| Payment term | T/T,L/C |
| Supply Ability | 500 Pcs Per Month |
| Packaging Detials | Wooden Package, Plywood Case, Carton, Neutral Packing |
| Place of Origin | China Original |
About ABB TPS52-F32 Two Hole Turbine Casing Design 51000
The turbine hood is an essential component of TPL-A and TPL-C
turbochargers. It has two main functions:
First, to protect the bearing casing from the high temperatures
caused by the exhaust gases and, second, to
guide the exhaust gas with minimum losses through the gas outlet
casing.
To allow for thermal expansion of the sheet metal, the turbine hood
is clamped between the bearing casing
and gas outlet casing (see figure below).
The turbine hood is designed to ensure it remains properly clamped
over the complete lifetime of the turbo-
charger. However, vibration, an increase in the number of load
changes or turbine-side cleaning cycles can
cause wear at the clamping shoulders of the bearing casing and the
gas outlet casing. Increased wear causes
a reduction in the clamping force, which could result in
uncontrolled movement of the turbine hood.
Part List:
51000 Turbine casing
51002 Fastening strips
52400 Gas outlet flange
52406 (in customer spare part set) Gasket
52408 Metal C-ring
56001 Nozzle ring
56005 rupture ring
57210 Burst ring
XHL453866R1#SERVICE KIT 5
XHL453799R1#SERVICE KIT 6#
97070 Service Kit 1
97076 Service Kit 2
97084 SPARE PARTS KIT 6
32109 SOCKET SCREW
32101 plain bearing bush
32111 auxiliary bearing
21002 pistion ring
32108 pistion ring
32222 o-ring
25000 compressor wheel
