Hand touch screen PLC program corrugated sheet roll forming machine
with automatic producing
1. Hand touch screen PLC program corrugated sheet roll forming
machine with automatic producing
---- One machine can produce one profile, we provide two working
speed: 8-12m/min and 20-25m/min.
---- Hand touch screen with PLC control program, only need input
the length and quantity, machine will finish the produce
automatically.
---- A wonderful design for machine feeding, runing, cutting, only
2 operators can keep machine running smoothly.
---- All raw materials and electric parts are high standard, ensure
machine in good quality.
2. Hand touch screen PLC program corrugated sheet roll forming
machine with automatic producing parameters
| Item Name | Specification |
| Processing material | Color steel coil, Galvanized coil, Aluminized zinc coil or as your
customized |
| Processing thickness (mm) | 0.3-0.8mm or as your customized |
| Material of rollers | High grade 45# steel, Processed by CNC lathe, Hardening and
tempering, polishing, hard chrome plated 0.05-0.07mm |
| Material of shafts | 45# steel |
| Diameter of shafts | 70mm or as your customized |
| Forming speed | 8-12 m/min or as your customized |
| Under frame | 350 H-beam |
| Sidewall | 16mm |
| Connect bar | 25mm, zinc plated |
| Forming steps | 10-18 or as your customized |
| Control system | Delta PLC and Inverter |
| Suitable power | 380V, 50 Hz, 3 phase or according to your need |
| Drive mode | Chain and sprocket, chain size 1 inch |
| Main motor | 3-5.5kw |
| Hydraulic pump station | 3-5.5kw |
| Cutting model | Hydraulic profile cutting |
| Dimension of the machine | 7.5m-11m×1.5mm×1.2m |
| Weight of the machine | 3.5 ton -6 ton |
| Machine Components |
| No. | Name | QTY |
| 1 | Manual uncoiler | 1 set |
| 2 | Feeding and leveling device | 1 set |
| 3 | Roll forming system | 1 set |
| 4 | Hydraulic punching and cutting | 1 set |
| 5 | Product support frame | 1 set |
| 6 | PLC Control System | 1 set |
