Automatic Switching Control Tensile Testing Machine For Universal Materials

    Buy cheap Automatic Switching Control Tensile Testing Machine For Universal Materials from wholesalers

    Buy cheap Automatic Switching Control Tensile Testing Machine For Universal Materials from wholesalers
    • Buy cheap Automatic Switching Control Tensile Testing Machine For Universal Materials from wholesalers

    Automatic Switching Control Tensile Testing Machine For Universal Materials

    Ask Lasest Price
    Brand Name : BAXIT
    Model Number : BXT-T100
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, Western Union
    Supply Ability : 10Set per day
    Delivery Time : 5-8 days
    • Product Details
    • Company Profile

    Automatic Switching Control Tensile Testing Machine For Universal Materials

    Tensile strength tester / Tension impact Test Machine


    QUICK DETAIL


    This machine is a new type of universal material testing machine combined with electronic technology and mechanical transmission. It is designed and manufactured according to GB, JIS, ASTM, DIN and other standards. It is used for the testing of metal and non-metal materials. Such as: castings, steel, copper, non-ferrous metals.
    Wire can be stretched, compressed, bent, sheared, peeled, torn, two-point extension, and other tests. Can automatically calculate the tensile strength, elongation, yield strength, set stress, fixed edge stress, elastic modulus and other parameters


    Tensile strength tester/Tension impact Test MachineTensile strength tester/Tension impact Test Machine


    ADVANTAGES


    1. Adjustable fixed device is added to adjust the upper and lower height of the measurement. The position is adjustable and the precision is high.
    2. Automatic switching control, with stepless speed regulation.
    3. Using a single arm structure, the structure is more stable
    4. The fixture and the fixing table are made of hard material. The screw holes can be used M6 screws to fix the measured object with the fixture.
    5. Compatible and equipped with a variety of styles of force gauge, can be configured with a digital push-pull gauge or pointer push-pull gauge
    6. With three specifications of the test frame for customers to choose, effective test range can reach 200mm, 400mm, 700mm


    TECHNICAL PARAMETERS


    ModelGlo-200-500NGlo-400-500NGlo-700-500NGlo-200-1000NGlo-400-1000NGlo-700-1000N
    Test load500N1000N
    Test range200mm400mm700mm200mm400mm700mm
    Test speed25-280mm
    Power supplyAC220V
    Extermal size280*340*780280*340*980280*340*1270280*340*780280*340*980280*340*1270
    Weight(kg)384042384042
