    80 W Amorphous Cilicon BIPV Solar Panels Thin Film Modules ISO14001 Certification

    Ask Lasest Price
    Brand Name : Rixin
    Model Number : RXJP3-ABS80
    Certification : TUV, CE, ISO9001, ISO14001, OHSAS18000
    Price : Negotiable
    Payment Terms : T/T, L/C
    Supply Ability : 3GW/YEAR
    Delivery Time : 15 working days
    • Product Details
    • Company Profile

    80 W Amorphous Cilicon BIPV Solar Panels Thin Film Modules ISO14001 Certification

    80W Amorphous cilicon solar panel Thin Film BIPV solar Modules


    Main features

    1. Lower cost, excellent weak light effect.

    2. Induce astigmatism/reflected light.

    3. Generate electricity even in rainy and cloudy days.

    4. Better high temperature performance, the total generating capacity is higher.

    5. No raw material limation, can be manufactured in mass, higher VOC.

    6. Less degradation, over 20 years' life time.


    Performance parameters

    80W Amorphous cilicon solar panel Thin Film BIPV solar Modules
    TypeRXJP3–ABS80

    Electricity

    Performance


    Wp

    Peak Power Output (W)

    80Wp

    Vmp

    Maximum Power Voltage (V)

    99.2 V

    Imp

    Maximum Power Current

    0.81 A

    Isc

    Short Circuit Current(A)

    1.0 A

    Voc

    Open Circuit Voltage(V)

    132.9V
    Max system voltage1000V

    Mechanical

    Performance


    Working Temperature-40-85℃
    Front cover3.2mm thin film solar cell
    Back cover4mm float glass

    Solar panel

    Temperature

    Coefficient


    Power TK(Pm)-0.21%/℃
    Open Circuit Voltage TK(VOC)-0.28%/℃
    Short Circuit Current TK(ISC)+0.04%/℃
    Dimension(mm)1300*1100*7.8
    Module weight(kg)27KG
