Large Clear Span Aluminum Pvc Event Tent For Outdoor Meeting / Temporary Tent Structures

Large clear span aluminum and pvc tent for outdoor meeting, large outdoor meeting, temporary structure for conference

Liri Tent series range embodies design simplicity and structural strength providing the user with a first class, proved professional tent system, making it the preferred choice of compact marquee design with many of the world’s leading venues.

Olympic Games, FIFA World Cup, PGA golf Game, motor sport, world skiing or light athletic championships. Liri Tent series are to be found at nearly all renowned sport events, permanent space concepts for clubs. Such as basketball, golf tennis, football and ice hockey.

Liri Tent design and deliver the best possible solution for all requirements, which can be covered through tents of different dimensions and with every different fittings, one and two floors.

Specification for 50 width tent

Frame struss: hard pressed extruded aluminium 6061/T6(15HW) which can last more than 20 years.
Fabric cover: high quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability, etc.
Connector: strong hot-dip galvanized steel
Allowed temperature condition: -30 degree Celsius~+70 degree Celsius
Wind load: max. 100km/h (can be reinforced)
Snow load: 75kg/sqm (snow can't stay if use big degree roof pitch design)
Easy to be assembled and dismantled, movable.
No pole inside, 100% available interior space.

2. Superiority of tents

2.1 Sizes can be customized
2.2 Allowed temperature condition: -30 degree Celsius~+70 degree Celsius
2.3 No pole inside, 100% room is available
2.4 Trouble-free and easy transportation, erection, dismantling, storage
2.5 Wind loading up from 80 to 100 km per hour
2.6 Multifunctional, widely used for different request

3. Optional Accessories of Transparent Tent

Covers: colourful cover, transparent cover, inflatable roof cover
Windows: dome or square clear PVC windows, mesh window, glass window for glass wall
Wooden Flooring System: VIP cassette flooring, simple cassette flooring
Doors: double-wing glass door, single-wing glass door, glass fire door, aluminium door, rolling shutter(automatic or manual)
Wall: soft PVC fabric wall, glass wall, ABS hard wall, sandwich panel wall, steel plate wall
Fixing Methods: ground anchors, weight plate, expandable bolts
Rain Gutters:inner roof beam rain gutter or rain gutter between two similar tents
Other Optional Items: table, chair, lighting, AC, carpet, installation tools etc.

4. Liri Tent Series

Liri Architecture Technology (Guangdong) Co., Ltd. was established in 1997 and headquartered in Zhuhai, Guangdong. With nearly 600 employees and a total factory area of 120,000 square meters. The company has branches in Beijing, Shanghai, Guangzhou, Changsha, Chengdu, the United States, Thailand, and Africa, and products have been exported to more than 130 countries and regions.

Focusing on mobile modular structures for nearly 30 years, Liri has not only established good cooperative relationships with the Canton Fair, Airshow China, East Asian Commodity Exhibition, Asian Games, Universiade, National Games, etc., but also collaborated with major campsite brands to build multiple outdoor high-end luxury glamping tent campsites. Professional design, manufacturing, sales, and rental of aluminum alloy modular tent structures, Air Domes, and glamping tents, providing one-stop temporary space solutions for various exhibitions, brand showrooms, events, sports venues and industrial warehousing, campsite hotels, and other fields.
