    110V Crack Testing Equipment Magnetic Particle Testing For Surface Crack Testing HCDX-230

    Ask Lasest Price
    Brand Name : HUATEC
    Model Number : HCDX-230
    Certification : ISO, CE, GOST
    Payment Terms : T/T, Paypal, Western Union
    Supply Ability : 500pcs per month
    Delivery Time : 1-4days
    • Product Details
    • Company Profile

    110V Crack Testing Equipment Magnetic Particle Testing For Surface Crack Testing HCDX-230


    110V Crack testing equipment Magnetic Particle Testing For Surface Crack Testing HCDX-230

    Defect examples: Defect location:
    Inclusions Seams Surface and subsurface Ideal for: Fatigue cracks
    Shrink cracks Tears Laps Field testing pot inspections
    Welding slag Grinding cracks In-service inspections
    Quenching cracks Demanding environments
    Weld inspection


    The HCDX-230 series is a durable, high-strength AC, AC/DC, DC magnetic yoke designed to detect surface and sub-surface indications in the most rugged applications.

    Featuring sealed chemical-resistant construction, articulating legs to contour to any part shape and robust strain-relieved twelve-foot cord for field use, the HCDX-230 is ideal for inspection of welds and other remote testing.

    Solid-state controls allow the operator to use AC magnetic fields for surface indications or DC magnetic fields for sub-surface indications to meet all inspection needs.

    The charging type magnetic particle flaw detector has the characteristics of compact structure, reasonable layout, small size, light weight and convenient portability. The flaw detector can be used directly in alternating current, and can also be used for AC magnetization power supply (AC battery pack) and DC magnetized power supply (DC-AC inverter battery pack), which is efficient and portable. It is suitable for hull weld inspection, high altitude steel structure weld detection and pressure vessel internal operation. This instrument is suitable for steel structure parts of power, metallurgy, petrochemical, machinery and other industries, such as boiler, pressure vessel, pressure pipe, ship body weld and welding structure of various types of ferromagnetic material surface and magnetic particle flaw detection of near surface defect.

    This instrument conforms to the standard requirements of JB/T7411-2012, ASME BPVC,ASTM E709,ASTM E1444,ASTM E3024."electromagnetic yoke flaw detector technical condition".

    Product features
    Sealed, durable construction
    Chemical and abrasion resistant
    AC and DC operation options for surface and sub-surface inspection
    Exceeds ASTM lifting specifications

    The three modes of power supply can be freely chosen:
    There are places directly connected to AC power supply, which can be directly connected with AC power supply.
    It is possible to use AC magnetized power supply (DC-AC inverter battery pack) to supply AC power without any direct insertion to AC power supply.
    The DC magnetizing power supply (DC battery pack) can be used to realize the DC magnetization function.
    AC magnetizing power supply (DC-AC inverter battery pack) has the functions of voltage regulation, overcharge, over current and over discharge.
    When the lifting force is not enough, the power is automatically cut off to ensure the sensitivity of flaw detection.
    The power display function can display the current battery power, and has the function of sound and light alarm.
    Built in microcomputer chip to stabilize output voltage and ensure detection sensitivity.
    Adjustable magnetization
    Special working waist bag can carry battery pack, magnetic suspension, contrast agent, yoke probe, etc.
    Technical parameter
    Working temperature: -10 ~ +40 C
    Storage temperature: -20 ~ 50 C
    Relative humidity: <80% non condensation
    Work temperature rise: <18 C
    Temporary load rate: >50%
    Sensitivity: A1 standard test piece 15/50 groove clearly displayed.
    AC minimum power hoisting power: >4.5kg (44N)
    DC minimum power hoisting power: >18.1kg (177N)


    Model guide

    1. Technical Specifications:

    Model

    Categories

    HCDX-230
    DC-AC inverter
    With battery

    HCDX-230
    DC

    HCDX-230
    AC

    HCDX-230E
    AC-DC switch
    No battery

    Power supply110V/220V 50/60Hz-12V110V/220V 50/60Hz 12/V110V/220V 50/60Hz110V/220V 50/60Hz
    Charging power110V/220V 50/60Hz-12V110V/220V 50/60Hz 12V//
    BatteryYD-2 Inverter batteryRechargeable battery//
    Working current

    AC 3A
    DC 3A

    3A3A3A(AC-DC Switching Converters)
    Charging duration3h3h//
    Battery duration6h-8h6h-8h//
    Battery size60×96×170mm60×96×170mm
    Aperture time3 ~ 5 seconds on / 3 to 5 seconds off
    Magnetizing length50-200mm50-200mm50-200mm50-240mm

    Lift
    force

    AC≥6㎏/≥4.8㎏≥5.5㎏
    DC≥18.5㎏≥18.5㎏/≥25㎏
    WeightProbe3.2㎏3.2㎏3.2㎏3.5㎏

    Battery
    box

    2.9㎏2.9㎏//

    Figure
    size

    Probe208×48×148208×48×148208×48×148210×60×260

    Battery
    box

    170×96x60170×96x60//



    Standard configuration:

    HCDX-230 DC-AC Inverter AC yoke kit
    Magnetic powder flaw detector host 1
    Power line 1
    Rechargeable Inverter DC battery pack (DC magnetized power supply 110V/220V 50/60Hz) 1
    DC power backpack 1
    Power adapter 1
    DC output connection line 1
    Instrument box 1
    Certificate 1
    Manual 1

    HCDX-230 DC
    Magnetic powder flaw detector host 1
    Power line 1
    Rechargeable DC battery pack (DC magnetized power supply) 1
    DC power backpack 1
    Power adapter 1
    DC output connection line 1
    Instrument box 1
    Certificate 1
    Manual 1


    HCDX-230 AC
    Magnetic powder flaw detector host 1
    Power line 1
    Instrument box 1
    Certificate 1
    Manual 1

    HCDX-230E AC-DC switch
    Magnetic powder flaw detector host 1
    Power line 1
    Instrument box 1
    3A (AC-DC Switching Converters)
    Certificate 1
    Manual 1
