| LCM |
| Brand | YODA |
| Panel Type | TFT-LCD |
| Application | Indoor |
| Panel Size | 18.5inch |
| Display Colors | 8- bit, 16.7M |
| Number of Pixels | 1920×1080P |
| Viewing Angle | 89°(U) / 89°(D) / 89°(L) / 89°(R) |
| Luminance of White | 200 cd/m² |
| Working Life | More than 6000hrs |
| Audio |
| Power consumption | 8Ω/5W × 2 |
| Audio Mode | Stereo |
| Charging Interfaces |
| USB fast charging ports | 10nos |
| Power Sockets | 2nos |
| Android Mother Board |
| OS | Android |
| CPU | RK3288 |
| RAM | DDRIII 2G |
| Storage | 8GB |
| Video Output | HDMI Video Output |
| Audio Output | Dual-channel stereo audio output |
| Network | LAN(RJ45) / Wireless |
| Interfaces | USB 2.0 × 2,RJ 45(LAN) × 1,Mirco SD/TF × 1,HDMI OUT × 1 |
| RTC | Support |
| Language | English (Default, multi language supported) |
| Multimedia Broadcasting System |
| System Framework | B(Browser) / S(Server),It is suitable for LAN and public network.
The background service program has no strict requirements on the
operating system. It can open Internet explorer's login control
background on any computer and manage the terminal group. |
| Split Screen | When production can be arbitrary tensile drag and drop all kinds of
material (video, photo, subtitle, PDF, web, clock, weather, timing)
area and the size, in support of the flashy color, background color
and font, font size, words scrolling Settings. |
| Program Template | Built-in variety of program templates, support to design and make
templates, provide program preview function, what you see is
income. |
| Task Mode | Supporting rotation and interplanting. |
| Remote Monitoring | It can support real-time screen capture, terminal report and
abnormal analysis ,remote standby, wake up, restart and format disk |
| Terminal Settings | Support time volume, time brightness, timing switch, etc. |
| Program Download | FTP protocol is used to support regular download and automatic
download of two modes. |
| Remote Real-time Monitoring | The remote real-time monitoring terminal network connection status
and monitoring the dynamic playback screen is playing, so that the
user can manage without the display end of the operation. |
| Timing Switch | System can set the terminal weekly plan several boot, shutdown time
every day, and can set up several rounds a day (up to 10) time
switch machine, this is not only more convenient management
terminal, and not artificial switch machine to increase the work
efficiency to reduce unnecessary waste electricity at night. |
| Terminal Block | Different publishing groups can be customized according to the
geographical location or business type of the distribution points
in the actual application.The direct release of instructions to the
group during the management or distribution of programs makes user
management easier and more efficient when the number of terminals
is displayed. |
| Review Mechanism | Support material audit and broadcast task package audit, provide
system management security, support material background grid
transformation and remote preview audit, support task package
scheduling time axis management, at a clear. |
| Off-line Play | Support under the network abnormal finished program directly
imported into the storage card to play, just need to export the
programs in the U disk, mobile storage, will U disk access player,
the player will automatically from the U disk copy need to import
the broadcast after the completion of the program and the U disk,
can be broadcast. |
| Statistical Reports | Support to play detailed statistics, play report statistics and so
on. |
| Other |
| Appearance | Classic type, Stents shapes, Chassis, Other customized |
| Certificate | CE FCC ROHS |
| Warranty | 1 year |
| Funcation | 1. Built-in Thermal Printer - 80mm width paper output
2. Built-in Scanner - support both QR and Bar code
3. With a hanger & holder for POS machine 4. NFC card reader for option |
