    Auto Spindle Bottle Capping Machine

    Ask Lasest Price
    Brand Name : NPACK
    Model Number : NP-LC
    Certification : CE/ISO
    Price : 9500USD to 16500USD
    Supply Ability : 100 sets per year
    Delivery Time : 15 working days
    • Product Details
    • Company Profile

    Auto Spindle Bottle Capping Machine

    NP-LC Full automatic Linear bottle capper Spindle capping machine is suitable for spindle screw caps, locked caps, and spray caps and so on. The caps can be metal , plastic.


    Features
    1.We adopt the mode of 'one motor controls one capping wheel', which can ensure the machine to work stably and keep consistent torque under long term working condition.

    2. The clamping belts can be adjusted separately, which allow the machine to be suitable for capping bottles with various heights and shapes.

    3. If you choose the optional cap guiding system together with the machine,
    it will then also fit for pump caps.

    4. The convenient construction adjustment system is equipped with precise
    ruler and counter.

    5. The mainframe can be lifted and descended automatically by a motor.

    6.WE have change the bottoms operation to Touch screen operation


    NAME MODELNP-LC Automatic linear spindle capping machine
    Capacity0~200b/m(subject to bottles and cap size)
    Bottle and cap diameterΦ10120 subject to samples
    Bottle Height40~460mm
    Spindle capping machine dimensionL1060*W896*H1620mm
    VoltageAC 220V 50Hz
    Power1600W
    Weight500kg
    Cap Feed systemElevator feeder
    DimensionL880×W1000×H2600mm

    Ⅰ. Brief Introduction:

    With good conveying ability, lift elevator is designed to elevate different types of caps with different specifications. The elevator is suitable to automatically convey plastic and metal bottle caps into the caps collection device of capper main machine.


    The conveying chain adopts high strength wear proof plate chain, lengthening the service life of chains and hopper. The high elevate height, slow stable conveying speed and advanced design, ensure the stability of the whole machine. Easy operation and maintenance with little consumerable spare parts.


    Elevating speed is about:1.25m/s


    Main Feature:

    1.: Simple structure and easy operation

    2.: 304 stainless steel material thus easy maintain and cleaning

    3.: Hopper(Volume at about 150L) is capable to store numbers of caps

    4.: Constant elevating speed and stepless adjustment.

    5.: AC 220V motor drive, good generality


    Ⅱ. Connection and adjustment

    1. Hyaline PC cover position adjustment(As picture 1 below)

    The distance between the inner side of hyaline PC cover and the convey chain shall 2-6mm more than the height of the caps.
