Non dig HDD Drill Pipe For Ditch Witch Horizontal Directional Drilling Machine

Ask Lasest Price
Brand Name :	NO
Model Number :	Φ50 Φ60 Φ73 Φ83 Φ89 Φ102 Φ114 Φ127 Φ140 Φ168
Certification :	API,ISO9001
Price :	Negotiation
Supply Ability :	10,000pcs per month
Delivery Time :	10-30 working days after payment

Add to Cart

Product Details
Company Profile

Non dig HDD Drill Pipe For Ditch Witch Horizontal Directional Drilling Machine

Non dig HDD Drill Pipe For Ditch Witch Horizontal Directional Drilling Machine

Description of Non-dig HDD Drill Pipe For Ditch Witch Horizontal Directional Drilling Machine:

Non-dig integral forged drill pipes are used to transmit drill torque and pullback force during the directional drilling project. The manufacturing process of the pipes is very strict because the pipes must bear twist, pullback, friction and vibration in the course of drilling. The raw material used in Double Horse is all the alloy steel produced

Our HDD drill rods have two main types: 1) forged one piece;2) Friction welding

Specification of the forged drill Pipe for Vermeer HDD machine

Model Of the rig	Connection	Dimension of the drilling Pipe					Tempering and Quenching	Min Bending Radius	Max Torque
		OD of the Tube	Wall Thickness	OD of the joints /upset	Working Length	Weight	Tempering and Quenching	Min Bending Radius	Max Torque
		(mm)	(mm)	(mm)	(mm)	( kg)	Grade	(m)	Nm
D7×11, D9X13	Firestick 1	42	6.5	48	1829	12	S135	29	2000
D10X14,D10X15	Firestick 1	42	6.5	48	3048	20	S135	29	2000
D16×20,D18×22	Firestick 1	48	6.5	54	3048	23.5	S135	30	3000
D24X26	Firestick 1	54	7	57	3048	25	S135	31	4000
D24×40	Firestick 1	60.3	7.5	66.7	3048	35	S135	33	6300
D40X40	Firestick 1	60.3	7.5	66.7	4572	50	S135	33	6300
D33×44, D36×50	Firestick 1 or 2	60.3	7.5	70	3048	36	S135	33	6772
D33×44, D36×50	Firestick 1 or 2	60.3	7.5	70	4572	51	S135	33	6772
D36×50	Firestick 1	60.3	7.5	70	3048	36	S135	33	6772
D36×50	Firestick 1	60.3	7.5	70	4572	51	S135	33	6772
D36×50	Firestick 1	66.7	8	78	3048	40	S135	40	9000
D36×50	Firestick 1	66.7	8	78	4572	55	S135	40	9000
D50×100/Uni60x70	Firestick 1	73	10	83	3048	55	S135	51	16000
D50×100	Firestick 1	73	10	83	4572	78	S135	51	16000
D50X100/D80×100	Firestick 1	89	10	92	4572	96	S135	72	18000
D100×120	Firestick 2	89	10	104	6096	130	S135	72	24000
D100×120	Firestick 1	89	11.5	111.5	6096	150	S135	80	27000

Specification of the forged drill Pipe for Ditch Witch HDD machine

Model Of the rig	Connection	Dimension of the drilling Pipe					Tempering and Quenching	Min Bending Radius	Max Torque
		OD of the Tube	Wall Thickness (mm)	OD of the joints /upset	Working Length	Weight	Tempering and Quenching	Min Bending Radius	Max Torque
		(mm)	(mm)	(mm)	(m)	( kg)	Grade	(m)	Nm
JT820/920	DW	42	6.5	50.8	2	13	S135	26	2000
JT920L	DW	42	6.5	50.8	3	21	S135	26	2000
JT1720 /1720M1	DW	52	6.5	63	3	25	S135	30	3200
JT2020M1	DW	60	7.5	66.7	3	35	S135	33	6300
JT2720	DW	60	7.5	70	3	36	S135	33	6772
JT2720M1/3020M1	DW	68	8	76	3	40	S135	33	7000
JT4020	DW	73	10	82.5	4.5	51	S135	51	16000
JT4020M1	DW	83	9	89	4.5	84	S135	65	18000
JT7020 /8020	DW	89	10	101.6	4.5	100	S135	72	24000

Specification of the forged drill Pipe for Case HDD machine

Model Of the rig	connection	Dimension of the drilling Pipe					Tempering and Quenching	Min Bending Radius	Max Torque
		OD of the Tube	Wall Thickness	OD of the joints	Working Length	Weight	Tempering and Quenching	Min Bending Radius	Max Torque
		(mm)	(mm)	(mm)	(m)	( kg)	Grade	(m)	Nm
Case 6030	Case	60.3	7.5	66.7	3.048	35	S135	33	6300

Specification of the forged drill Pipe for Chinese all Brand HDD machine

Size	Connection	Dimension of the drilling Pipe					Tempering and Quenching	Min Bending Radius	Max Torque
		OD of the Tube	Wall Thickness	OD of the joints /upset	Working Length	Weight	Tempering and Quenching	Min Bending Radius	Max Torque
		(mm)	(mm)	(mm)	(mm)	( kg)	Grade	(m)	Nm
50x2000mm	DH50	50	6.5	57	2000	20	S135	29	3000
60X3000mm	DH60-1	60	6.5	66.7	3000	35	S135	33	6300
60X3000mm	DH60-1	60	6.5	70	3000	35	S135	33	6300
73X3000mm	NC23(DH23)	73	7.5	80	3000	45	S135	45	13000
73x3000mm	NC26(2 3/8IF)	73	10	87	3000	55	S135	51	16000
83X3000mm	D80 Firestick1	83	9	92	3000	58	S135	65	18000
83x4500mm	D80 Firestick1	83	9	92	4500	84	S135	65	18000
89X4500mm	NC31(2 7/8IF)	89	10	104.8	4500	100	S135	72	24000

The specification list HDD drill pipe (Friction welding)

Nomiated Dimension

Nomiated weight

Tube

joints

Bearing torque comparison

material

Upse tting

OD
(mm)

Wall thickness of the pipe
(mm)

thread

OD of the joints
d(mm)

ID of the joints
d(mm)

Dimeter of the angling
DF(mm)

Big clamp space of the pin joints
LPB (mm)

Big clamp space of the box joints
LPB (mm)

OD of the welding joints
DTE/
DPE (mm)

3 1/2

13.3

R
G
S

88.9

9.35 (11.4)

NC31

104.8
104.8
104.8

50.8
50.8
41.28

100.41
100.41
100.41

177.8
177.8
177.8
