Nitrogen and Oxygen Cryogenic Air Separation Plant Gas Separation Equipment

    Buy cheap Nitrogen and Oxygen Cryogenic Air Separation Plant Gas Separation Equipment from wholesalers

    Buy cheap Nitrogen and Oxygen Cryogenic Air Separation Plant Gas Separation Equipment from wholesalers
    • Buy cheap Nitrogen and Oxygen Cryogenic Air Separation Plant Gas Separation Equipment from wholesalers

    Nitrogen and Oxygen Cryogenic Air Separation Plant Gas Separation Equipment

    Ask Lasest Price
    Brand Name : Chenrui
    Model Number : KDO
    Certification : ISO9001/ISO1400/18001
    Price : USD 10000-300000/set
    Payment Terms : L/C, T/T
    Supply Ability : 10 set per quarter
    Delivery Time : 90 days
    • Product Details
    • Company Profile

    Nitrogen and Oxygen Cryogenic Air Separation Plant Gas Separation Equipment

    Nitrogen and Oxygen Cryogenic Air Separation Plant Gas Separation Equipment


    1. Small Cryogenic Air Separator Plant

    ModelOxygen capacity (Nm3/h)Oxygen purity (%)Oxygen outlet pressureNitrogen capacity (Nm3/h)Nitrogen purity (%)Nitrogen outlet pressureStart-up time
    KDON-50/1005099.6

    20KPa

    Or as user’s requirement

    100<1015KPa or as user’s requirement12
    KDON-100/20010020012
    KDON-150/600150600
    KDON-170/40017040012
    KDON-350/80035080016
    KDON-550/1200550120016
    KDON-1000/10001200100024

    2. High Purity Nitrogen Air Separator Plant

    Technical Parameters

    ModelNitrogen capacity (Nm3/h)Purity (ppmo2)Pressure (Kpa)Liquid nitrogen capacity (L/h)Liquid nitrogen purity (ppmo2)Air capacity request (Nm3/h)Working pressure (Kpa)Working cycle time (M)
    KDN-5050≤50.7//1950.956
    KDN-1001000.73600.956
    KDN-300/20Y300≤30.6320≤311000.812
    KDN-600/30Y6000.633018000.712
    KDN-800/40Y8000.234018000.713
    KDN-1000/50Y10000.235032000.714
    KDN-2000/100Y20000.610055000.715
    KDN-3000/25Y30000.620070000.716

    3. Full Liquid Air Separation Unit Data Sheet

    Comparing with gaseous Air Separation Unit, full Liquid Air Separation Unit and Gases Liquefaction Plant need more cold in the whole process.To meet different demands from customers, different processes like air cycle process, nitrogen cycle process, high and low temperature booster turbine expanding process or low temperature refrigerating process etc. are adopted to reduce the power consumption.In order to achieve stable and reliable operating of plant, PLC control system or DCS control system are recommended.

    4. Product Specification:

    1.Air Separation Unit with normal temperature molecular sieves purification, booster-turbo expander, low-pressure rectification column, and argon extraction system according to client’s requirement.

    2.According to the product requirement, external compression,internal compression (air boost,nitrogen boost),self- pressurization and other processes can be offered.

    3.Blocking structure design of ASU, quick installation on site.

    4.Extra low pressure process of ASU which reduce air compressor exhaust pressure and operation cost.

    5.Advanced argon extraction process and higher argon extraction rate.

    5. FAQ:

    1. Are you manufacturer or Trade Company?
    We are the manufacturer of nitrogen Generator, founded in 2005

    2. What's the order nitrogen generator process?
    a. Inquiry---provide us all clear requirements.
    b. Quotation---official quotation form with all clear specifications.
    c. Printing file--- PDF, Ai, CDR, PSD, the picture resolution must be at least 300 dpi.
    d. Contract confirmation---provide correct contract details.
    e. Payment terms--- Negotiable.
    f. Production---mass production
    g. Shipping--- by sea, air or courier. Detailed picture of package will be provided.
    h. Installation and commissioning

    3. What terms of payment you use?
    T/T, L/C etc.

    4. How to get a prompt quotation of nitrogen Generator?
    When you send the inquiry to us, pls kindly send it with below technical information.
    1) N2 flow rate: _____Nm3/hr( or How many cylinders do you want to fill per day(24hours))
    2) N2 purity: _____%
    3) N2 discharge pressure: _____Bar
    4) Voltages and Frequency : ______V/PH/HZ
    5) Application:

    6) Project Location:
