Super High Pressure Servo Vane Pumps, applicable to Servo hydraulic
system
1. Adopt the flexible structure with a spring between the bottom of
the vanes and the slot, in ordere to
start at low speed,applicable to servo hydraulic system.
2. Adopt pin type and double lips vane structure, suitable to the
fast switching of high and low speed,
right and left rotation working status of the servo pumps.
3. The product is developed based on the T7 series pin type vane
pumps, with higher pressure , the
maximum pressure can reach 32MPA; With higher volume efficiency,
the maximum can reach more than
95%; lower noise level and the minimum noise is 62db
4 The products is with mature technology, reliable and strong
anti-pollution , applicable to the hydraulic
systems with anti-wear hydraulic oil fluid
5. Flexible for installing , there are many inlet and outlet port
positions for choice.
6.Insert cartridge kit structure,very convenient for repair.
Main Parameter
| Series | Flow code | displacement ml/r | max pressure | max speed | min speed |
| T7BS | E03 | 9.8 | 32 | 3600 | 50 |
| T7BS | E04 | 12.8 | 32 | 3600 | 50 |
| T7BS | E05 | 15.9 | 32 | 3600 | 50 |
| T7BS | E06 | 19.8 | 32 | 3600 | 50 |
| T7BS | E07 | 22.5 | 32 | 3600 | 50 |
| T7BS | E08 | 24.9 | 32 | 3600 | 50 |
| T7BS | E10 | 31.8 | 32 | 3600 | 50 |
| T7BS | E12 | 41 | 30 | 3000 | 50 |
| T7BS | E15 | 50 | 28 | 3000 | 50 |
| T7DS | E14 | 44 | 30 | 3000 | 50 |
| T7DS | E17 | 55 | 30 | 3000 | 50 |
| T7DS | E20 | 66 | 30 | 3000 | 50 |
| T7DS | E22 | 70.3 | 30 | 3000 | 50 |
| T7DS | E24 | 81.1 | 30 | 3000 | 50 |
| T7DS | E28 | 90 | 30 | 3000 | 50 |
| T7DS | E31 | 99.2 | 30 | 3000 | 50 |
| T7DS | E35 | 113.4 | 28 | 2800 | 50 |
| T7DS | E38 | 120.6 | 28 | 2800 | 50 |
| T7DS | E42 | 137.5 | 26 | 2500 | 50 |
