magnetostrictive level transmitter / transducer with indicator
meter fuel level sensor
Description of magnetostrictive level transmitter / transducer with
indicator meter fuel level sensor:
Magnetostrictive liquid level transmitter works: generating a start
pulse from inside the vault electronic circuit, when the initial
pulse propagation in the waveguide filaments, while producing a
rotating magnetic field direction along the waveguide wire, and
when the magnetic field and the magnetic ring or a float mechanism
can pick up a permanent magnetic field meet magnetostrictive
effect, so that the occurrence of the waveguide twist yarn, the
twist is mounted in the electronic compartment perceived and
converted into corresponding current pulses through the electronic
circuit calculates the time difference between the two pulses can
be measured accurately measure the displacement and level.
Specification of magnetostrictive level transmitter / transducer
with indicator meter fuel level sensor:
01, Range: 0 to 12 m, (can be customized according to user
requirements);
02 Power supply: 24VDC;
03, the signal output: 4 ~ 20mA standard current signal;
04, the measurement accuracy: ± 1mm or 0.3% FS (current output
type);
05, working pressure: ≤4.0Mpa;
06, media requirements: Density ≥0.5g / cm3, viscosity ≤0.005Pa.s;
07, operating temperature: T1: 0 ~ 70 ℃, T2: -25 ~ + 80 ℃, T3: -40
~ + 85 ℃;
08, repeatability error: better than 0.01% FS;
09, Resolution: better than 0.01% FS
10. Hysteresis: better than 0.01% FS
11, temperature effects: ± 0.007% FS / ℃
12, zero adjustment range: 20% FS
13, a full-scale adjustment range: 20% FS
14, the frequency response time: 0.2 ~ 5ms (based on range size);
15. Connection: flange connection;
16, proof mark: flameproof: EXd Ⅱ BT4
17, shell protection: IP65
18, the spindle pressure: ≤34Mpa
