Customized Powder Or Liquid Agitator Mixer , Vertical Chemical Mixers Agitators

High Quality Industrial Vertical Powder or Liquid Agitator Mixer for Chemical Industry

Main Usage

Yongyi agitator, anchor agitator, dispersion disk, two blades, propulsion blades, four blades, multi-blade, stretch blade are mainly used in paints, pigments, dyes, paints, ink, food, adhesives, medicine, daily chemicals and other liquids, The comminution, agitation and grinding of emulsion and liquid-solid materials are the conventional parts of disperser, grinder, pulverizer, mixer, emulsifier and other mechanical equipment.

Technical Parameter

1. Blade Agitator

This type of agitator is most basic. At low speed, the flow is horizontal circulation; at high speed, the flow is radial; With baffle, the flow is cycling up and down. The agitator is applicable to mix, homogenize and dissolve low-viscosity liquid, transfer heat and crystallize. When liquid is high-viscosity, the agitator is working under laminar conditions, and the stirrer is multi-layer and at low-speed.
Application conditions: Dj / D = 0.35-0.9; Applicable viscosity is commonly less than 2000cp, the maximum viscosity is 100000cp; linear velocity: 1-5m / s, N / n in the table refers to for the stirrer blade strength allowed values, the design temperature is <200 ° C, N refers to calculated power (kw), and n refers to revolutions per minute of stirrer.

Dimension

2. Open Turbine Agitator with Four Oblique Blades

Open turbine agitator with four oblique blades is similar to open turbine agitator with six flat blades. Under the same conditions, stirring intensity of the former is weaker than that of the latter, and its comprehensive performance is better when the higher speed is required. It’s one of the most widely used agitators.
According to different requirements, stabilizer can be designed as cylindrical stabilizer or stabilizer fin.
If stabilizer is designed as stabilizer fin, model P will be replaced by model W.
Application conditions: Dj / D = 0.2-0.8, often 0.4 is choosed; Applicable viscosity is commonly less than 50000cp; linear velocity is 1-10 (m / s); wide-type agitator B / Dj = 0.2, narrow-type agitator B / Dj = 0.125.

Dimension

Chengdu Yongyi Pump Industry Co., Ltd is a professional enterprise involved in manufacturing and marketing the best quality pumps and mixer for a wide range and variety of customers home and abroad. Chengdu Yongyi Pump Industry Co., Ltd is located in Chengdu, Sichuan province, China, about 50km to Chengdu Shuangliu International Airport and very close to China Railway Express.

Chengdu Yongyi Pump Industry Co., Ltd established in 1995, now, over 90% of our workers and engineers have many years of production experience, with production ability of 20 sets per day. They could finish the procedure of design, casting, machining, assembly and testing independently.

With main products of pumps and mixers, our products cover more than 1, 000 varieties in more than 10 series, including chemical process pump, slurry pump, vortex pump, desulfurization pump and agitators and many more. They are widely used in chemical, metallurgy, mineral, electricity, coal industry and so on.

The company has advanced design platform, using PRO / ENGINEER, SolidWorks and other three-dimensional software for product structure analysis; Has hydraulic machinery, casting and smelting, mechanical processing, heat treatment and other technical personnel, has multiple patent technologies, is a member unit of phosphorus and sulfur industry association, the key test platform and the joint base of Xihua university, has obtained the industrial design center granted by Chengdu city and high-tech enterprises in Chengdu and the big taxpayers of Chengdu Qingbaijiang district.

Through very stringent quality and enterprise audit procedure, we have passed ISO9001 international quality system authorization in 2015. Also finished Product Traceability System is adopted to ensure the product quality & production management.


Good management, cohesive team, good service system and rich experience give this company a solid foundation to continued development. New products are being on continually researched and developed to meet the demand of variable markets.

This competitive company strives forward to create value for the customers and satisfy various consumers' needs
