    Full Color Perimeter Advertising Boards / Outdoor Rgb LED Display Board

    Ask Lasest Price
    Brand Name : BST
    Model Number : ODF-6
    Certification : CE, RoHS, FCC, ISO
    Price : Negotiation
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 5000sqm/months
    Delivery Time : 10-20 days after receive payment
    • Product Details
    • Company Profile

    Full Color Perimeter Advertising Boards / Outdoor Rgb LED Display Board

    Full Color Perimeter Advertising Boards / Outdoor Rgb LED Display Board


    Perimeter Advertising Boards Quick Detail:

    The Main Features of Front & Rear Dual-channel Maintenance LED panel:
    1. Screws become unnecessary between LED modules and cabinets; without screws, the demounting and mounting process becomes a lot easier. Within a few seconds, the LED module can be demounted off the cabinet so that the working efficiency is highly enhanced.
    2. Cabinets become a lot thin and light, with thickness 115mm and weight 35kg in maximum. Compared with similar products in the existing market, it is more light and thinner.
    3. More space has been saved, compared with large space needed for maintenance service within tradtional LED Display.

    Perimeter Advertising Boards Features:


    Outdoor high resolution, all-water proof. High brightness with super low power consumption, smart structure design and long time proven technology.


    Perimeter Advertising Boards Application:

    Outdoor advertising, billboards, rental business ,allow both front and rear service.


    Perimeter Advertising Boards Description:

    BST front serviceable led sign is a innovative technology, which leading the whole industry trend. This LED display series allow both front and rear service, which could enable tons of convenience the customers.
    Easy installation and light weight can make it amount in the wall or lift against the wall.

    Front accessible design allows customers to make thinner LED display, which is suitable for some special locations where there is no more space for rear maintenance.

    Module Front Service means fix the module on the cabinet from front of the sign, once the module needs service, can take out the module from front side.

    Easy and fast installation, light weight, can hang mount on the wall, Lifting rely on the wall. Front side maintenance LED screen which eliminates the maintain space for the rear screen to achieve the former maintenance, so we can make it very thin for some special installing sites. Dust and Water proof, wide range of working temperature (-35°C~70°C), can be used in all kinds of circumstance, such as moisture, smog, storm.

    front serviceable led display is suitable for all range of pixel pitch, and currently the best sold items are: P8mm, P10mm, and so on. Based on the traditional cabinet structure, the module fast lock makes it not only labor-saving, but also easy and fast service convenient. The cabinet measurement, material and thinness are all can be customized.

    Perimeter Advertising Boards Specifications:


    SPECIFICATION
    ODF-4ODF-6ODF-10
    Physical Pitch4.81mm6.67mm10mm
    Pixel ConfigurationSMD1921SMD2727SMD3535 / DIP346
    Pixel Density43,264 pixels/sqm22,500 pixels/sqm10,000pixels/sqm
    Module Dimensions
    (WXH)(mm)
    250X250320X320320X320
    Panel Dimensions(mm)1000X10001280X9601280X960
    No. of Modules Per
    Panel(WXH)
    4X44X34X3
    Physical Resolution
    of Module(WXH)
    52X5248X4832X32
    Physical Resolution
    of Panel(WXH)
    208X208192X144128X96
    Panel MaterialCold SteelCold SteelCold Steel
    Weight per panel
    (kg)
    657979
    Processing16bit16bit16bit
    Driving Method1/9 scan1/4 scan1/4scan or 1/2scan
    Average Power
    Consumption
    250 W/panel360 W/panel360 W/panel
    Refresh Rate>1920Hz>1920Hz>1920Hz
    Brightess≥5,500nits≥6,500nits≥6,500nits
    Horizontal Viewing
    Angle
    140°160°160° /110°
    Vertical Viewing
    Angle
    140°140°140° / 70°
    Expected Lifetime100,000Hrs100,000Hrs100,000Hrs
    IP Rationg
    (Front/Rear)
    IP 65/IP54IP 65/IP54IP 65/IP54
    Working Temperature—20℃-50℃/—40℃-60℃—20℃-50℃ /10%-90%—20℃-50℃ /10%-90%
    Working Humidity10%-90%RH/10%-85%RH—20℃-50℃ /10%-90%—20℃-50℃ /10%-90%
