4-1/2 Inch Round ESP Cable Protector Carbon Steel Material Stamping
Type
ESP Cable Protector Brief Introduction
UNITOOLS is a professional producer for ESP cables, Control line
and Encapsulated bundles protector .
Our protector use channels to shield cables and lines when they
across coupling to prevent damage during installation or retrieval
of completions .
ESP Cable Protector Application
• ESP cable
• Subsurface safety valves control line
• Chemical injection line
• Permanent Gauges
• Intelligent Wells
• Fiber Optic
• Coiled tubing
ESP Cable Protector Features
A: Each clamp has two Friction pads ,they will have pre-deformation
to facilitate clamping cables and lines .
Meanwhile ,we added 1mm for each indents to increase clamping force
, That’s one of our differents.
B: we have triple convex pads on the channel to improve gripping
characteristics without damaging cables ,
Except that It will increase Pulling force ,because of the friction
pads .
C: Two parallel hinge pin make full contact with Tubular .Other
protectors’ hinge pin will have a little tapered
D: The teeth of clamp is tapered , It will be easier than paralel
teeth when insert wedge-lock pin . Meanwhile, tapered pin with
dimples to secure the clamp doesn’t fall off the tubing .
ESP Cable Protector Standard Size Chart
