Full Automatic Plastic Bottle Blowing Machine , Pet Bottle Manufacturing Machine

Name: Full Automatic Plastic Bottle Blowing Machine Pet Bottle Manufacturing Machine
Brand: Reliable
Price: 1 USD

Ask Lasest Price
Brand Name :	Reliable
Model Number :	RM-2000
Certification :	CE ISO SGS
Price :	Negotiable
Payment Terms :	L/C, T/T
Supply Ability :	15 Set/Sets per Month Automatic Used PET Bottle Stretch Blowing Molding Machine
Delivery Time :	35-45 working days

Add to Cart

Product Details
Company Profile

Full Automatic Plastic Bottle Blowing Machine , Pet Bottle Manufacturing Machine

Plastics Pet Molding Blow Supplier Automatic Bottle Blowing Machine

The element of our machines uses the international brands and the processing is completed by professional technicians.
Our products have been sold to the whole world

Flow chart

High Pressure Air Compressor→Air Storage Tank→Air Filter→ Refrigerated Air Dryer→Air Filter→ Water Chiller→Low Pressure Air Compressor→PET Preforms→ heat preform→ stretch→ blowing→ bottles

Product Description

It is the most reliable blowing machine for making water bottles, juice bottles, and carbonated drinks bottles. This blowing machine can blow PET bottles in different shapes, also, the machine can be customized according to the customer special demands. Full automatic blowing machine can make bottle from 200ml to 2000ml with capacity from 2000 to 10000 bottles per hour.

Advantages

1. Multi adjusting device placed on the preform heater increases the machine's quality.

2. The machine is equipped with specially designed PLC control system.

3. Pneumatic unit provides power for machine movement including machine driving and bottle blowing.

4. The machine has a plenty of assistant unit to increase the machine's performance such as air storage unit to keep the air pressure stable grease-lubricating unit to reduce mechanical parts' wear and tear and multi-utilization air entry unit to meet air compressed air high-pressure single entry mode and high-pressure & low-pressure double entry mode.

5. The machine preform heater adopts independent temperature control unit for each heating zone to offer ideal temperature for various preforms.

6. The machine preform heater is equipped with air-cooling and water-cooling device to remove the remained heat on preform loader and prevent preform neck from deformation. And reliable air exhaust system placed on the heater keeps heating temperature continuous and stable during preform heating process.

7. Automation controlling item adopts international high-end computer system, heating, collecting and measuring perform temperature with simulation input and output module.

Technology data

Type	RM-2000
output	according to bottle shape	2000BPH
product specification	bottle body diameter	20mm-100mm
	bottle height	50mm-350mm
	bottle mouth diameter	15mm-38mm
mold	cavity	2 cavity
	mold thickness	200mm
	mold effective area	800X800mm
Main power	power ,voltage	380v 3Phase /220v 3Phase 50/60HZ
Main power	Install machine power/actural use power	68kw/15kw
air source	low pressure air compressor	2.0m3/min 1.0MPa
	high pressure air compressor	3.6m3/min 3.0MPa
	cold-dry machine	2.0m3/min 3.0MPa 1set
cooling water	cooling quantity	15L/min
main machine size	LWH	280819581920mm/4600kg
feeder size	LWH	20009502480mm/250kg

Outlooking
