2019 Q235 adjustable warehouse pallet racking/storage rack system
Description:
The pallet racking is used to store unitized pallet cargo, which
are safe and convenient, suitable for various warehouses and
directly access goods. It is the simplest and most widely used
shelf. The upright frame are non-welded connected by horizontal and
vertical bracing with bin. They are used with forklifts and are
free to pick up any cargo in any position. Because the pallet
racking is suitable for cargo storage with large variety and large
quantity, in order to facilitate access, the designed roadway will
be more, so the ground usage rate is relatively low.
Details:
| 1. Features: | 1)Beam levels are adjustable in 50mm pitch interval. |
| 2)Different sizes, various specifications and colors are available
according to customers’ different needs. |
| 3)Maximizes space use ratio in any warehouse configuration while
retaining optimum product accessibility. |
| 4)Strength and rigidity prevents compression damage to goods. |
| 5)Bottom level of pallets can be stored on the floor, lowering
structure costs. |
| 2. Material: | High grade Q235B Steel |
| 3. Finish: | High-quality Powder Coating Finishing. |
| 4. Load Capacity & Dimension: | Loading capacity: 200-3000 kgs UDL/beam level. |
| Height: 1000-12000mm |
| Depth: 800-1200mm |
| Length: 1000-4000mm |
| Specail sizes also avaiable to specific storage needs. |
| 5. Main Parts Specs: | 1) Uprights:40*60mm,40*80mm,60*80mm, 70*90mm, etc. |
| 2) Box beams: 50*80mm, 50*100mm, 50*110mm, 50*120mm, 50*140mm,
etc., |
| 3) Horizontal & diagonal bracings, upright footplates, safety
locking pins, bolts & nuts, anchors and all necessary components. |
| 6. CE certified. | Our warehouse rack certified by FEM. |
| 7. Quick Delivery. | Within 15 days for ordinary order quantity. Big production capacity
allow us in a position to make quick delivery. |
| 8. Package | Layer boards in cartions and upright posts wrapped by Bubble Films. |
| 9. ODM/OEM | Yes |
| 10. MOQ | 20sets |
Feature:
1. The shelf structure is stable. Due to the high load bearing
requirements of pallet racks, there are special requirements for
the stability of pallet racks. The tray feet must be fitted with
ground expansion screws to ensure the stability of the tray
shelves.
2. No need for laminates, which can maximize cost savings.
3. The three-dimensional structure can make full use of warehouse
space, improve warehouse capacity utilization, and expand warehouse
storage capacity
4. The loading capacity is large, not easy to be deformed. And the
connection is also reliable with easy dis-assembly and assembly.
Application:
This kind of rack designed for warehouse, workshop and factory use
but also commonly used in garages, storerooms and picking areas.
