CE certificate 5 axis ATC CNC Router machine SYNTEC for EPS FOAM
WOOD
Applicable industry:
5-axis machining center cnc router machine is a high-precision
machining equipment, which is mainly used to process complex
surfaces, special-shaped components and high-precision components.
It can be processed in multiple directions, including X, Y, Z axis
and A, B axis. The following are the main uses of the 5-axis
machining center:
1. Automobile and aviation field: 5-axis machining center can process complex parts of automobile
and aircraft, such as hub, fuselage, etc., with high accuracy and
efficiency.
2. Precision machinery manufacturing: 5-axis machining center can process various precision machinery
parts, such as gears, bearings, guide rails, etc., with the
characteristics of high precision and high strength.
3. Plastic arts: 5-axis machining center can produce various plastic arts, such as
sculpture, sculpture, etc., with the characteristics of high
precision and high degree of freedom.
4. Medical field: 5-axis machining center can produce various medical devices,
artificial limbs, etc., with the characteristics of high accuracy
and high personalization.
5. Ship manufacturing: 5-axis machining center can process various ship parts, such as
propeller, propeller, etc., with the characteristics of high
precision and high strength.
In general, the 5-axis cnc router milling machine is a
high-precision and high-efficiency machining equipment, which can
be processed in multiple directions, suitable for processing needs
in various fields, and has broad application prospects.
Features:
1. Totally have X/Y/Z/A/B five aixs fast working efficy
2. Diversified control processing speed can control the working
speed, traveling speed, dropping tool speed, lowering tool speed,
greatly improve the quality and efficiency.
Intelligent processing cross-border protection function can prevent
mechanical collision due to excessive processing of design file.
3. Z-axis travel can be heightened to 2.1 meters, so that very
suitable for processing large-scale three-dimensional surface.
4. Adopt TAIWAN Syntec 8axis numerical control system, high
machining accuracy and high speed.
5. The Japan THK rails.and the Germany original rotating arm ensure
the accuracy and strength of the mechanical
6. Advanced Syntec system with intelligent program
You no need prepare separate post processor just make a suitable 5
axis design in softare then input Syntec system then will be ok.
Machine main components:
1. Adopting Taiwan Syntec 8 axis new generation control system
A. It can be connected with many software, which has the
characteristics of simple operation, fast processing speed and
stable operation
B. Breakpoint memory function can automatically memorize
breakpoints in case of unexpected cutter breakage and power
failure, and realize the function of continuous processing at
breakpoints
C. Intelligent cross-border protection function can prevent
excessive processing caused by machine collision
D. It is with wireless handle that operation is more convenient. It
can realize virtual processing, actual processing, locating the
origin, suspending and other operations
E. The USB interface and the processing program can be directly
processed from the U disk.
F. Intelligent program. No need extra post processor just need to
input ready 5axis design then system will work it to right toolpath
| Machine Features | RSKM25-Z |
| X,Y,Z working area | 2000*3000*1000mm |
| Table size | 2050*3040mm |
| Spindle | 9kw HSD spindle, 1000-24000rpm |
| Motor | Yaskawa Servo motor and driver |
| Moving mode | Table moving |
| C travelling | ±180° |
| A travelling | ±360° |
| Beam spacing(MM) | 4260 |
| Beam Height(MM) | 2150 |
| Vacuum pump | Dry Vacuum pump 5.5kw |
| product fixed form | vacuum table |
| Tool magazine | Round tool tool magazine (6 positions) |
| X, Y, Z Travelling Potioning Accuracy | ±0.03/300mm |
| X, Y, Z Travelling Repositioning Accuracy | ±0.05mm |
| Frame | Cast steel |
| X, Y structure | rack and pinion drive, THK rail linear bearing from Japan |
| Max Rapid Travel Rate | 45,000mm/min |
| Max working speed | 30,000mm/min |
| Z Axis | 20m/min |
| c Axis | 20m/min |
| A Axis | 20m/min |
| Machine size | 4260*2150*3300 |
| Total Power(kw) | 24KW |
| Maximum lifting weights | 20T |
| Working voltage | AC380V/50Hz |
| Command languages | G code,F/S |
| Control system | OSAI |
| Collet | BT40 |
| Limit switch | Omron |
Working samples:
After Sales Service:
Training-----One technician will be assigned to client company for
3 working days free of charge. Customer is responsible for
accomodation, food and air tickets.
Email--------24hours email support from Monday to Friday
Call-----------24hours call support From Monday to Friday
