Optical Isolation RS232 to RS485/422 converter Model485P

    Buy cheap Optical Isolation RS232 to RS485/422 converter Model485P from wholesalers

    Buy cheap Optical Isolation RS232 to RS485/422 converter Model485P from wholesalers
    • Buy cheap Optical Isolation RS232 to RS485/422 converter Model485P from wholesalers

    Optical Isolation RS232 to RS485/422 converter Model485P

    Ask Lasest Price
    Brand Name : 3onedata
    Model Number : MODEL485P
    Certification : CE, FCC, RoHS
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 3000 sets per month
    Delivery Time : 7 Working Days
    • Product Details
    • Company Profile

    Optical Isolation RS232 to RS485/422 converter Model485P

    Optical Isolation RS232 to RS485/422 converter

    Introduction:
    Model485P is a high performance, more function RS-232/485/422 interface converter. The product configure out connect power, optic-electrical isolation more than 2.5KV. Have small volume, far transmission distance, high rate, steadily performance and so on. It is abroad used in industry control system, It is an interface convert product that have good between performance to price. Adopt itself adapt interface technique, no use for setup switch.
    Features:
    1. 9VDC power input, 2500V optical isolation
    2. Plug-and-Play(hot-pluggable, data format auto-sensing & self-adjusting)
    3. Data direction auto-turnaround, no flow control is necessary
    4. 1500W surge protection, 15KV ESD protection
    5. 1800m transfer distance (115200bps)
    6. RS-485/RS-422 connector RJ45, DB9M or 5 bit terminal block
    Specification:
    Standards: EIA RS-232C, RS-485, RS422 standard
    RS-232 signal: TX, RX, GND
    RS-422 signal: T+, T-, R+, R-, GND
    RS-485 signal: D+, D-, GND
    Working mode: Asynchronism, point to point or multi point, 2 wire half-duplex,4 wire full duplex
    Baud rate: 300~115200bps, auto test serial signal rate detect signal speed automatically, zero delay time
    Flow control: Data direction auto-turnaround, no flow control is required
    Transfer distance: RS-485/422 side:1.8Km,115200bps
    RS-232 side: no less than 5m
    Max number of drops: 128 nodes
    Optical isolation: 2500V
    Port protect: 1500W surge protection,15KV ESD protection
    Power
    Power input: 9VDC power input
    Consumption: Static less than 120mA, dynamic less than 350mA
    Environment
    Operating temperature: -10°C to 60°C
    Storage temperature: -40°C to 85°C
    Humidity: 5% to 95%(no condensation)
    Appearance
    Dimensions: 93.0mm×62.4mm×22.0mm
    Material: Iron(shell)
    Color: White
    Weight: 200g
    Warranty: 5 years
    Approvals: FCC, CE, RoHS approvals
