4 Digit Led 7 Segment Display RGB Custom Led Display Bicolor Seven
Segment LED Module
Quick Detail of 7 segment LED display
A 7 Segment LED Display is a electronic device that contains an array of 8 individual
LEDs.
Each of the 8 segments that make up the display can be either be on
the on state or the off state. Depending on which LEDs are lit
determines the character which is displayed on the LED. The LED can
be made to show a wide range of characters, including all numerical
digits from 0-9.
The versatility of a 7 segment display lies in the fact that it can
be a numerical value indicator. LED displays are used in all types
of products, including alarm clocks, scoreboards, and all other
signs showing character output.
Specification of 4 Digit 7 segment LED Display
| Parameter | Symbol | Condition | Min | Typ | Max | Unit |
| Forward Voltage | Vf | If=20mA | 2.8 | | 3.3 | V |
| Reverse Voltage | Vr | Ir=10uA | 30 | | | V |
| Luminous Intensty | Iv | If=20mA | | 30 | | mcd |
| Spectrum With Of Half Value | △λ | If=20mA | | 30 | | nm |
| Wavelength | Dλ | If=20mA | | 473 | | |
| Parameter | Symbol | Ratings | Unit |
| Forward Current(per dice) | Ipm | 20 | mA |
| Reverse Voltage(per dice) | Vr | 5 | V |
| Power Dissipation(per dice) | Pm | 80 | mW |
| Operating Temperature Range | Topr | -40~+120 | ºC |
| Storage Temperature Range | Tstg | -40~+120 | ºC |
| Solder Temperature(3 sec) | Th | 260 | ºC |
Application About Digit Number LED Display
-- Audio Equipment or instrument panels;
-- General using for digital indicators;
-- Multimedia products;
-- Bank exchange rate display;
-- LED clock display;
-- Display for gas station and other various display areas of
equipment/machine.
Advantages of seven segment LED display
1. Emitte lights under the condition of low voltage and small
current drive; can be compatible with CMOS, ITL circuit;
2. Short response time when emitt lights (<0.1uS), excellent
monochromaticity and high-frequency, big viewing angle, standard
brightness, low power consumption, stable performance;
3. Prompt reply your inquiry within 24 Hrs;
4. Professional first class staffs answering your demands very
smoothly;
5. Whatever big or small order, we will serve you with our best
quality and superior service;
6. 100% QC inspection before shipping;
7. TUV listed meterials, Competitive price;
FAQ About Digital Number LED Display
Q1. Can I have a sample order for your products?
A: For standard type,Yes, we welcome sample order to test and check
quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-7 days, mass production time needs 1-3 weeks.
Q3. Do you have any MOQ limit for the order?
A: Low MOQ, 1pc for sample checking is available for most types.
Q4. How to proceed an order?
A: Firstly let us know your requirements or application. Secondly
We quote according to your requirements or our suggestions. Thirdly
customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q5. Is it OK to print my logo on the product?
A: Yes. Please inform us formally before our production and confirm
the design firstly based on our sample.
Q6: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control
system and the defective rate will be less than 0.2%. Secondly,
during the guarantee period, we will send new lights with new order
for small quantity.
For defective batch products, we will resend them to you or we can
discuss the solution including re-call according to real situation.
