FESTO,Push-in T-fitting,CRQST-3/8-10,164206,4052568136918,Pneumatic
Tube Fittings
Nominal size:5.9mm
Order no:164206
Brand:FESTO
GTIN:4052568136918
Specifications:CRQST-3/8-10
Weight:62g
Size of pack:1
Material housing:High-alloy stainless steel
Product Technical Data
| Feature | Value |
| Size | Standard |
| Nominal size | 5.9mm |
| Mounting position | optional |
| Size of pack | 1 |
| Design | Push-pull principle |
| Note on operating and pilot medium | Lubricated operation possible |
| Corrosion resistance class CRC | 4 - Very high corrosion stress |
| Product weight | 62g |
| Number of outputs | 2 |
| Number of supply lines | 1 |
| Material housing | High-alloy stainless steel |
| Material release ring | High-alloy stainless steel |
| Material tubing seal | FPM |
| Material tubing clamp component | High-alloy stainless steel |
| Note on materials | RoHS-compliant |
| Suitable cables | PFAN |
Another size as follow
| Specifications | Order NO | GTIN | Weight(g) | EXW Price | Size of pack |
| CRQST-1/4-8 | 164204 | 4052568073244 | 38 | USD30-40 | 1 |
| CRQST-1/4-10 | 164205 | 4052568136901 | 56 | USD30-40 | 1 |
| CRQST-1/8-6 | 164202 | 4052568073220 | 25 | USD30-40 | 1 |
| CRQST-1/8-8 | 164203 | 4052568073237 | 33 | USD30-40 | 1 |
| CRQST-3/8-10 | 164206 | 4052568136918 | 62 | USD30-40 | 1 |
| CRQST-1/8-8 | 164203 | 4052568073237 | 85 | USD30-40 | 1 |
| CRQST-1/2-12 | 164208 | 4052568136932 | 105 | USD30-40 | 1 |
| CRQST-1/2-16 | 164209 | 4052568136949 | 128 | USD35-45 | 1 |
Orientable Male thread with external hex
Sectional view
About product
1.Simply "plug and work".
2.Reliably connected.
3.Orientable.
4.Highest process reliability in every case
5.Unlimited use in the food industry
6.Corrosion resistance CRC 4 and chemical resistance with approval
for use in the food and packaging industry.
7.For pneumatic applications with a temperature range up to 120 °C
and a pressure range up to 10 bar.
8.Joints with different thread specifications are often used
between pipelines to complete the connection.
Competitive Advantage
Our product features: Our Services Guarantee:
1) Competitive price 1) Prompt respond (Reply with 24 hours)
2) Good quality 2) Free Samples (Customer pay for the delivery
cost)
3) Professional Packaging, 3) Registration support.
4) Produce according to Customers’ instruction 4) Photos/videos are
available during production.
5) None delay shipment
5) Loading inspection, and send loading photos before shipment.
After-sale Service
We can provide a series of after-sale service, such as product
introduction, mounting, debugging, technical support and so on.
There are many specifications of connectors, price and delivery
time. Welcome to inquire.
