Brand Name : | ORSTE |
Model Number : | OMT-605-W ~ OMT-1010-HTW |
Certification : | CE, ISO, SGS |
Price : | 800 ~ 1200 USD/Set |
Payment Terms : | TT, LC, Paypal, West Union, Cash |
Supply Ability : | 500-3000 Sets / Year |
Delivery Time : | 7-15 days |
OMT-W Mold Temperature Controller Water Heater.pdf...
OMT-W series water heaters are widely used in the production of
plastic product. They are mainly applied to heat up the mold and
maintain temperature, also they can be used in other similar
fields. Through the principle of heat exchange, they can shorten
the product mold cycle and improve production efficiency.
Model | Max Temp. (℃) | Pipe Heater (kw) | Pump Power (kw) | Max. Pump Flow (L/Min) | Max. Pump Pressure (bar) | Heating Tank Number | Cooling Method | Cooling Water pipe (inch) | Circulating Water Pipe (inch) | Dimensions | Weight (kg) |
OMT-605-W | 120 | 6 | 0.375 | 42 | 2.5 | 1 | Direct Cooling | 1/2" | 3/8" | 580*260*650 | 34 |
OMT-610-W | 6 | 0.75 | 42 | 1 | 730*300*660 | 36 | |||||
OMT-610-WD | 6*2 | 0.75*2 | 42*2 | 2 | 980*390*860 | 72 | |||||
OMT-910-W | 9 | 0.75 | 56 | 1 | 730*300*660 | 36 | |||||
OMT-910-WD | 9*2 | 0.75*2 | 56*2 | 2 | 980*390*860 | 72 | |||||
OMT-1220-W | 12 | 1.5 | 235 | 1 | 980*390*860 | 68 | |||||
OMT-2430-W | 24 | 2.2 | 315 | 2 | 980*390*860 | 75 | |||||
OMT-3650-W | 36 | 3.75 | 495 | 3 | 980*390*860 | 83 | |||||
OMT-1010-HTW | 160 | 10 | 0.75 | 78 | 1 | Indirect Cooling | 980*390*860 | 70 |
![]() |
