20W Single mode nanosecond CW green fiber laser
Product introduction of CW green fiber laser
Our founder has PhD degree.
Gongda Laser has launched continuous laser with different power, aiming at the pain points such as severe spattering when welding
high reflection materials in the infrared band. The green laser
adopts the scheme of all fiber fundamental frequency plus external
frequency doubling, It has the advantages of high absorption, less
splash, high efficiency, high stability, high beam quality and so
on. The laser can also provide a flexible transmission mode coupled
to the optical fiber, which can be more conveniently matched with
automatic control and applied to the welding process of high
reactive materials such as copper. Due to its good output power
stability, excellent beam quality and high absorption rate of high
reflection materials, especially copper.
Product features of CW green fiber laser
1. Suitable for welding copper and other high reaction materials
2. Compared with infrared laser, there is almost no spatter in the
welding process
3. Faster absorption and high repeatability
4. Higher absorption rate, completely stable and reliable copper
welding process
Product application of CW green fiber laser
1. Cutting and welding of high reaction materials such as copper
Technical parameter of CW green fiber laser
| MODE | EO-LIGHT-CW-2-20~450 |
| Average power (W) | 20/30/40 | 50/60/70/80/90 | 100/120/150 | 200/250 | 300/350/400/450 |
| Working mode | Continuous /modulation |
| Maximum modulation frequency(KHz) | 5 |
| Central wavelength(nm) | 532 (±3) |
| Bandwidth 3dB(nm) | <1 |
| Long term power stability(%) | <3 |
| Beam quality( M2) | <1.3 |
| Operating voltage (VAC) | 220V |
| Rated power consumption(kW) | 0.6 | 1.2 | 1.6 | 2 | 2.5 |
| Working environment temperature(℃) | 5~35 |
| Cooling mode | water-cooling
|
Product size
