    Cast Iron Rubber Lined Flanged Butterfly Valve Customized Dn 100mm 125mm 150mm

    Customized Dn 100mm 125mm 150mm Cast Iron Rubber Lined Flanged Butterfly Valve


    Flanged Butterfly Valve Information


    The closing part is a disc-shaped butterfly plate, and the valve that rotates around a fixed shaft in the valve body to open, close and regulate fluid is called butterfly valve.
    The butterfly plate of rubber-lined butterfly valve is installed in the diameter direction of the pipeline. In the cylindrical passage of the butterfly valve body, the disc-shaped butterfly plate rotates around the axis of the valve stem, and the rotation angle is between 0 and 90 degrees. When it rotates to 90 degrees, the valve is fully open.
    The rubber lined flange batterfly valve should generally be installed horizontally in the pipeline.


    Form And Connection Dimensions


    Model

    DN

    Dimensions

    mm

    D

    D1(PN10)

    Z-φd

    L

    b-f

    D341X-10

    100

    215

    180

    8-φ18

    127

    22-3

    125

    245

    210

    8-φ18

    140

    24-3

    150

    280

    240

    8-φ23

    140

    24-3



    Characteristics


    The use of rubber seat seal makes it suitable for lower temperature and pressure, generally not more than 80℃ and not more than PN10, but also makes it have very excellent sealing performance. Therefore the rubber lined flange butterfly valve is most suitable for normal temperature liquid.


    Performance Specification


    Modle

    PN(MPa)

    Test Pressure(MPa)

    Applicable temperature

    Applicable media

    Strength(water)

    Sealing(water)

    D341X-10

    1.0

    1.5

    1.1

    ≤80℃

    Water

    D341X-16Q

    1.6

    2.4

    1.76

    ≤80℃

    Water


    Advantage


    1. Novel design, reasonable, unique structure, light weight, rapid opening and closing.
    2. Small operating torque, easy to operate, labor-saving dexterity.
    3. Can be installed in any position, easy maintenance.
    4. Seals can be replaced, sealing performance is reliable to achieve two-way seal zero leakage.
    5. Sealing materials, aging resistance, corrosion resistance, long service life and other characteristics.

    6.The design and manufacture of the rubber lined flange butterfly valve adopts GB12238 standard.
