    Portable Induction Brazing Machine Solder Carbide 15KW Induction Heater

    Ask Lasest Price
    Brand Name : ORD
    Model Number : HF-15KW
    Certification : CE,ISO, SGS
    Price : USD850-1050
    Payment Terms : T/T, D/P, D/A, Western Union, MoneyGram
    Supply Ability : 100SET/MONTH Goods in Stock
    Delivery Time : 5-6 work days
    • Product Details
    • Company Profile

    Portable Induction Brazing Machine Solder Carbide 15KW Induction Heater

    15KW Portable Induction Heating Machine Solder the Carbide ​


    Features:


    1. Infineon IGBT module and Inverting technologies of third generation been used; Higher reliability and lower maintenance cost.


    2. 100% Duty cycle, continuous working is allowed at maximum power output.


    3. Display of heating power and heating current and oscillating frequency;


    4. Simple to install, Installation can be done by unprofessional person very easily;


    5. Light weight, Protable type.


    6. 2M Coaxial Flexible cables Connection, can heat some workpiece that normal coil can not get it


    Technical Paramater:


    TypeHF-15KW
    Work power3Phase×380VAC 50-60HZ
    The range of operating voltage

    340V-430V(370-480)V AC


    Flexible Connect Cables2M
    Output Fluctuating power15KW
    Fluctuating frequency30-80KHZ
    Max Input Current15A
    Timing (Heat time, Retain time , Cool time)1-99S
    The flow rate of cooling water0.08-0.16 Mpa 7L/Min
    Water temperature protection point40℃
    Duty cycle100%(40degree room temperature)
    Weight43Kg
    Size

    600*230*480MM



    Application:

    Air conditioners, refrigerators, refrigeration system brass brazing, pipe brazing, as well as brass and aluminum tubes brazed

    the welding industry (brazing)
    1. Welding of various turning tools, planer, milling machining and cutting tools
    2. Welding of various diamond tools, such as: welding diamond saw blades, diamond drill
    3. Various shaped drill head column Button Bits, drill Yan briquette, riveting rod drill carbide brazed
    4. Various shearer teeth welding, various digging machine cutter welding
    5. Various mechanical welding tool

    Advantage of the Induction Heating Machine:

    1. More than 22 years experiences, high quality control, stable performance.

    2. CE Certificated

    3. Energy Saving Up to 20-30% compare with SCR machine.

    4. 5m flexible cables not reduce the power, it is easy to work some workpiece can not move it.

    5. Soft Switch Technology And prefect Protection system( Over Heat, Over Current, Under Voltage, Over Voltage, Phase Fail, Lack Water) enhance Good Reliability.
