    Industrial Embedded AGX Nvidia Xavier Jetson GPU Developer Kit 12V

    Ask Lasest Price
    Brand Name : PLINK
    Model Number : Y-C8-DEV-Xavier
    Price : To be discussed
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : 1+set+4weeks
    Delivery Time : 15-30 work days
    • Product Details
    • Company Profile

    Industrial Embedded AGX Nvidia Xavier Jetson GPU Developer Kit 12V


    Industrial Embedded AGX Nvidia Xavier Jetson GPU Developer Kit 12V


    Jetson AGX Xavier GPU

    NVIDIA Jetson AGX Xavier Developer Kit (Y-C8-DEV)


    NVIDIA Jetson AGX Xavier Module (32G) + Y-C8 Carrier Board + Cooling FAN


    The NVIDIA Jetson AGX Xavier module integrates a unified display controller (based on the NVIDIA NVDisplay architecture) and three independent display outputs. The Display Controller includes a Pixel Processing Engine that fetches pixel data to be processed from DRAM and generates up to six windows of rasterized display-ready pixel data. The instructions for processing the pixel data are captured by the display controller's Front End (FE) logic, which then generates the individual controls for the various stages of pixel processing. The pixel data to be processed are fetched in the Isochronous Memory Hub (IsoHub) then go through the specified pixel processing, including merging the cursor, in four pipe stages: Pre-Composition (Pre-comp); Composition (Comp); Post-Composition (Post-comp); and Raster Generation (RG). The rasterized display-ready pixel data are available for the separate panels/devices (referred to as display heads) and are fed through a multi-channel crossbar structure to the Serial Output Resources (SOR) in the Display Interface for the standard display output format, i.e. DP (Display Port) and HDMI (High Definition Multimedia Interface).


    Each of the display heads can be run at an independent clock rate, and each can drive a different display resolution. Each of the six display windows (A, B, C, D, E, F) can be arbitrarily assigned to any of the display Heads as required, then connected to any one of the display heads for desired output format.



    CPU8-core NVIDIA Carmel Arm® v8.2 64-bit CPU 8MB L2 + 4MB L3
    GPU512-core NVIDIA Volta GPU with 64 Tensor Cores
    USB Micro-B1
    USB Type-A1
    GPIO(3.3V)1
    SPI(3.3V)1
    I2C(3.3V)2
    RS 2322
    Debug(UART)1
    CAN (with on-board transceiver)2
    Networking1 x 10/100/1000 Ethernet/RJ45
    Power SupplyDC +12V
    Temperature-25~+65°C
    Size188mm × 170mm × 43mm
    NVIDIA Jetson AGX Xavier Module
    AI Perf32 TOPS
    GPU512-core NVIDIA Volta architecture GPU with 64 Tensor Cores
    CPU8-core Arm® Cortex®-A78AE v8.2 64-bit CPU 2MB L2 + 4MB L3
    Memory32GB 256-bitLPDDR4x 136.5GB/s
    Storage32GB eMMC 5.1
    CSI CameraUp to 6 cameras
    (36 via virtual channels)
    16 lanes MIPI CSI-2 | 8 lanes SLVS-EC
    D-PHY 1.2 (up to 40 Gbps)
    C-PHY 1.1 (up to 62 Gbps)
