606 Open Racks Data center 19 Inch 42U 4 post ddf computer network server rack open frame

    Buy cheap 606 Open Racks Data center 19 Inch 42U 4 post ddf computer network server rack open frame from wholesalers

    Buy cheap 606 Open Racks Data center 19 Inch 42U 4 post ddf computer network server rack open frame from wholesalers
    • Buy cheap 606 Open Racks Data center 19 Inch 42U 4 post ddf computer network server rack open frame from wholesalers

    606 Open Racks Data center 19 Inch 42U 4 post ddf computer network server rack open frame

    Ask Lasest Price
    Brand Name : Zion communication
    Model Number : 606 Open Racks
    Payment Terms : T/T
    Supply Ability : no limit
    Delivery Time : Normally 25 days after received the deposit.
    • Product Details
    • Company Profile

    606 Open Racks Data center 19 Inch 42U 4 post ddf computer network server rack open frame

    Technical Data

    Materials:
    　
    · SPCC Cold Rolled Steel;· others:2.0mm.
    · Column: 1.5mm;
    Colour:
    · ZC605.■■■■ ■■0■■: RAL7035.
    · ZC605.■■■■ ■■1■■: RAL9004.
    Loading Capacity:
    · Static loading:250KG.

    COMPLIANCE (Reference Standard)

    • Comply with ANSI/EIA RS-310-D
    • IEC60297-2
    • DIN41494;PART1; DIN41494;PART7

    Feature:

    May Installs The Fitting


    Main Part

    S/NSpecificationQtyMaterialSurface FinishRemark
    1Column2SPCC t1.5Powder coated·····
    2Plinth2SPCC t2.0Powder coated·····
    3Support Cross beam2SPCC t2.0Powder coated·····
    42″ heavy duty castor4·····
    AM6 screw & nuts20SteelColour zinc40pcs for over 33U
    BTrox tooling1SteelBlack·····

    Specification:

    Company Number.Part Number.RUWidth
    (mm)    		Depth(D)(mm)Height(H)
    (mm)    		Volume (CBM)
    7245106ZC606.6629.00. ■002960060014221420*260*140
    7245107ZC606.6633.00. ■003360060016001600*260*140
    7245108ZC606.6638.00. ■003860060018221820*260*140
    7245109ZC606.6642.00. ■004260060020002000*260*140
    7245110ZC606.6647.00. ■004760060022222220*260*140
    Quality 606 Open Racks Data center 19 Inch 42U 4 post ddf computer network server rack open frame for sale

    606 Open Racks Data center 19 Inch 42U 4 post ddf computer network server rack open frame
