Suitable For Composite Materials Computerized Universal Testing
Machine Ac 220v
Equipment’s Main Structure:
The whole structure is formed by the upper beam, the middle beam,
the lower beam and the bottom panel, with two pairs of ball
screw-rod and a vertical column. The full-digital AC Servo motor
drives the Reducer and the synchronic gear belt, so as to drive the
two pairs of high-precision and seamless ball screw-rod, and to
make the beam move up and down.
Using Scopes:
DDW Series Microcomputer Control Electronic Universal Testing
Machine (Normal Configuration Gate Type) is applicable for
tensile,compression and bending tests of materials with relatively
small test force, such as rubber, plastic, textile, waterproofing
material, cable, network wire, metal wire, metal rod, metal plate
and others. With attaching tools, it can also do compression and
bending tests.
Application:
The equipment is applicable to the measurement and analysis of
mechanical performance not only metal, non-metal material, but also
composite materials. It is widely used in aerospace, petrochemical,
machinery manufacturing, wire and cable, textiles, fibers,
plastics, rubber, ceramics, food, medicine packaging, plastic
pipes, plastic doors and windows, geotextile, film, wood, paper,
metal materials and manufacturing. According to GB, JIS, ASTM, DIN,
ISO and other standards, it can automatically strike the maximum
test force value breaking force value, yield strength, upper and
lower yield strength, tensile strength, compressive strength,
elongation, tensile modulus, flexural modulus test data etc.
Technical Parameters :
Model | GSKA-600 |
Support Customized | Yes |
Max capacity | 5kg,10kg,25kg,50kg,100kg,250kg,500kg (It is optional.) can be
setting |
Induction method : | Precision load cell (sensor) |
Max. Load Capacity : | 500kg |
Force Resolution/Accuracy: | ± 0.5% |
Accuracy class : | 0.5 |
Resolution: | 1/1,000,000 |
Test width: | 400mm(Standard specifications special specifications can be
customized) |
Test stroke : | Max.700 mm( included the fixture) |
Stroke Resolution: | 0.01mm |
Speed range: | 0.001-20inches/min |
Reference Machine Dimension: | 580*580*1250mm (W*D*H) Support Customized |
Power : | 1 phase 220V 50/60Hz |
Packing | Standard Export plywood case |
Force system | servo drives + Servo motor + precision ball screw drive |
Control system | Mechanical transmission + TM2101 + Pulse Command and Control System
control |
Measurement and Control System | TM2101 and control system; master controller uses the most advanced
32-bit ARM processor in the 21st century, the processing speed
of the Pentium-class common computer standards, compared to the
traditional 8 yuan SCM control system overall performance greatly
improved, faster operation, control accuracy higher |
Obtain data
| The key components are used America's most stable and
ultra-precision 24 yuan AD,
sampling rate of up to 2000 times / sec, can capture the power of
instantaneous change process, the entire file, regardless of the
resolution of up to 1,000,000 indexing |
Displacement Control: | Displacement encoder count with four frequency technology
So that the displacement of four times
the resolution can up to 0.0005mm |
Safety devices: | 1. overload, emergency stop device2. the upper and lower travel limit devices 3. the test is completed automatic shutdown device |
Reference standard | ASTM D903, ASTM E8 CNS11888, JIS K6854, PSTC7 ASTM
D903,GB/T16491CNS-11888,JIS K6854, PSTC-7 ,ASTM E4,ASTM D828,ASTM
D882,ASTM,D1938,ASTM D 412 ,ISO 8339ASTM D3330,ASTM F88,ASTM
F904,ISO 37,JIS P8113,QB/T 2358,QB/T 1130 , ISO 527 ,ISO 178 and
other
standards. |
Customer Support Services:
Ø Installation
Ø Training (Training customer employees)
Ø Calibration
Ø Preventative maintenance
Ø Replacement parts
Ø Assistance via phone or internet
Ø On-site diagnosis and repair/online diagnosis and repair
