Multi Function Double Roller Granulator Machine For Medicine Powder
Chemical Additive
Working Theory of Roller Granulator machine
This series of roller granulation is an extrusion slip model. Its
working principle is that the motor drives the belt and pulley,
transmits it to the driving shaft through the reducer, and
synchronizes with the driven shaft through the split gear to work
in opposite directions. The material is added from the feed hopper,
extruded by rollers, demolded and made into balls, and passed
through a pair of chains, sent to the crushing screen studio,
screened and separated into the finished granules (balls), and then
the returned material is mixed with the new material, and then
Granulate. With the continuous rotation of the motor and the
continuous entry of materials, mass production can be realized.
Specifications of Roller Granulator machine
| Model | DGZ—1 | DGZ—1.5 | DGZ—2 |
| Output | 1—1.5t/h | 1.5—2t/h | 2—2.5t/h |
| Forming Ratio | ≥85% | ≥85% | ≥85% |
| Power | 15kw | 18.5kw | 22lw |
| Feeding moisture | 2%—5% |
Feature of Roller Granulator machine
- Wide application like chemical fertilizer, food and medicine
granules production, etc.
- Materials can be normal Carbon steel or Stainless Steel
- Various final shape and size granules, like semi-round shape, bar
shape, cyclindrical shape, etc
- Dry granulating process without any further drying process
Application Of Roller Granulator machine
Our company wholeheartedly provides users with technical services
for complete sets of compound fertilizer equipment, including the
overall layout design, production technical guidance, complete set
supply, commissioning and production services for the annual output
of 10,000 to 100,000 tons of non-drying equipment.
