21.5 Inch Ips Tft Lcd Display 1920x1080 With Lvds Interface 30 Pins MV215FHM-N70

Ask Lasest Price
Brand Name :	BOE
Model Number :	MV215FHM-N70
Certification :	ROHS
Price :	USD55
Payment Terms :	T/T
Supply Ability :	5000pcs
Delivery Time :	5-8 work days

Add to Cart

Product Details
Company Profile

21.5 Inch Ips Tft Lcd Display 1920x1080 With Lvds Interface 30 Pins MV215FHM-N70

21.5 Inch Ips Tft Lcd Display 1920x1080 With Lvds Interface 30 Pins MV215FHM-N70

General Description:

MV215FHM-N70 each pixel is divided into RED, GREEN, BLUE dots which are arranged in vertical stripe and this module can display 16.7M colors. The TFT-LCD panel used for this module is ad apted for a low reflection and higher color type.

Specifications:

Parameter	Specification	Unit
Active area	476.064(H) × 267.786(V)	mm
Number of pixels	1920(H) × 1080(V)	pixels
Pixel pitch	0.24795(H) ×0.24795(V)	mm
Pixel arrangement	RGB Vertical stripe
Display colors	16.7M	colors
Display mode	Normally Black
Dimensional outline	484.464(H) x 284.486(V) x11(D) typ.	mm
Weight	1800(Typ.)	g
Bezel width (L/R/U/D)	4.2/4.2/4.2/ 12.5	mm
Surface Treatment	Haze 25%, 3H
Back-light	Horizontal arranged, 1-LED Lighting B ar type

Absolute Maximum Ratings:

Parameter	Symbol	Min.	Max.	Unit	Remarks
Power Supply Voltage	VDD	-0.3	5.5	V	Ta = 25℃
Logic Supply Voltage	VIN	VSS-0.3	VDD+0.3	V	Ta = 25℃
Operating Temperature	TOP	0	+50	℃
Storage Temperature	TST	-20	+60	℃
LCM Surface Temperatur e (Operation)	Tsurface	0	+65	℃

Electrical Specifications:

Parameter.			Min.	Typ.	Max.	Unit
Power Supply Voltage	VDD		4.5	5.0	5.5	V
Power Supply Current	IDD		-	500	1200	mA
In-Rush Current	IRUSH		-	2.0	3.0	A
Permissible Input Ripple Voltage	VRF		-	-	300	mV
High Level Differential Input Threshold Voltage	VIH		-	-	+ 100	mV
Low Level Differential Input Threshold Voltage	VIL		- 100	-	-	mV
Differential input voltage		VID	200	-	600	mV
Differential input common mode voltage	Vcm		1.0	1.2	1.5
Power Consumption	PD		-	2.5	6	W
	PBL		-	8.98	9.58	W
	Ptotal		-	11.48	15.58	W

Interface Connection:

Pin No	Symbol	Function
1	RXO0-	Negative Transmission data of Pixel 0 (ODD)
2	RXO0+	Positive Transmission data of Pixel 0 (ODD)
3	RXO1-	Negative Transmission data of Pixel 1 (ODD)
4	RXO1+	Positive Transmission data of Pixel 1 (ODD)
5	RXO2-	Negative Transmission data of Pixel 2 (ODD)
6	RXO2+	Positive Transmission data of Pixel 2 (ODD)
7	BIST	Bist function
8	RXOC-	Negative Transmission Clock (ODD)
9	RXOC+	Positive Transmission Clock (ODD)
10	RXO3-	Negative Transmission data of Pixel 3 (ODD)
11	RXO3+	Positive Transmission data of Pixel 3 (ODD)
12	RXE0-	Negative Transmission data of Pixel 0 (EVEN)
13	RXE0+	Positive Transmission data of Pixel 0 (EVEN)
14	GND	Power Ground
15	RXE1-	Negative Transmission data of Pixel 1 (EVEN)
16	RXE1+	Positive Transmission data of Pixel 1 (EVEN)
17	GNG	Power Ground
18	RXE2-	Negative Transmission data of Pixel 2 (EVEN)
19	RXE2+	Positive Transmission data of Pixel 2 (EVEN)
20	RXEC-	Negative Transmission Clock (EVEN)
21	RXEC+	Positive Transmission Clock (EVEN)
22	RXE3-	Negative Transmission data of Pixel 3 (EVEN)
23	RXE3+	Positive Transmission data of Pixel 3 (EVEN)
24	GND	Power Ground
25	NC	*Reserved for LCD manufacturer‘s use (CTL_DVR)
26	NC	*Reserved for LCD manufacturer‘s use (CE_DVR)
27	NC	No Connection
28	VDD	Power Supply: +5V
29	VDD
30	VDD

Handling Precautions:

1.As the electrostatic discharges may break the LCD module, handle the LCD module with care. Peel a protection sheet off from the LCD panel surface as slowly as possible.

2.As the LCD panel and back - light element are made from fragile glass material, impulse and pressure to the LCD module should be avoided.
