    FLANGE, LWN, RF,SIZE: 4"- 600#, SCH.20, RF, CS, ASTM A105 ASTM A182 F1

    Ask Lasest Price
    Brand Name : TOBO
    Model Number : ASTM A403 Grade WPS31254
    Certification : BV/ABS/LR/TUV/DNV/BIS/API/PED
    Price : negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 7500 tons per year
    Delivery Time : According to the qty
    • Product Details
    • Company Profile

    FLANGE, LWN, RF,SIZE: 4"- 600#, SCH.20, RF, CS, ASTM A105 ASTM A182 F1

    FLANGE, LWN, RF,SIZE: 4"- 600#, SCH.20, RF, CS, ASTM A105 ASTM A182 F1


    F1 A182 Alloy Steel Flanges is an alloy steel formulated for primary forming into wrought products. Its specified properties are appropriate for the annealed condition. F1 is the ASTM designation for this material and its UNS number is K12822.

    A182 F1 Cl2 Pipe Flanges has a very low electrical conductivity among wrought alloy steels in the same category. In addition, it has a moderately low embodied energy and base cost.
    A182 F1 material is a forging material specification for F1 grade alloy steel and it is used for manufacturing bare forgings or forged and machined products for applications which involves high temperature service.
    F1 steel Plate Flange is often a cost effective solution, when raised faces and hubs are not required and for the applications with no or low pressure at ambient temperatures.

    ASTM A182 F1 Lap Joint Flanges is a two piece device that is much like a weld-neck flange but also like a loose slip-on flange. It has an advantage to swivel around the stub end and pipelining.


    A182 F1 Cl2 Blind Flange Chemical Composition Chart

    GradeCMnSiPSCrMo
    Alloy Steel F10.15 max0.3-0.60.50.030.034-60.44-0.65

    Equivalent Of ASTM A182 Gr F1 Flanges

    STANDARDUNSDIN WERKSTOFF NR.DIN
    Alloy F1K128221.541515M03

    SA 182 Gr F1 Slip on Flange Mechanical Properties Analysis

    Tensile StrengthYield Strength (0.2%Offset)Elongation
    27548520 %

    ASTM A182 Gr F1 Flanges Pressure Rating

    Temperature °FClass 900Class 150Class 600Class 400Class 1500Class 300Class 2500
    -20 to 1002085265139092534706955785
    2002035260136090533956805660
    3001955230130587032606555435
    4001920200128085532006405330
    5001865170124583031056205180
    6001815140121080530256055040
    6501765125117578529405904905
    7001705110113575528405704730
    750159595106571026605304430
    800152580101567525405104230
    85014606597565024354854060
    90013505090060022454503745
    9508453556037514052802345
    1000495203302208251651370

    ASTM A182 Gr F1 Flanges Material Specification Chart

    SpecificationsASTM A182 / ASME SA182
    Size1/2″ (15 NB) to 48″ (1200NB)
    StandardsANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
    Class / Pressure150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
    StandardANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.

    ASME SA182 F1 Cl2 flanges Types

    F1 A182 Flange
    A182 F1 Cl2 Blind Flange
    ASTM A182 F1 Slip On flange
    ASTM A182 Gr F1 Flange
    A182 Grade F1 Plate Flange
    SA 182 Gr F1 Flanges
