LHA-4000 Gantry type H beam automatic welding machine

1.Purpose and working principle
This machine is an ideal equipment for automatic submerged arc welding of H steel. The work piece is placed on the bracket of the work piece (Fig. 1), Tilt 45 degrees to make the weld to be the position of the ship. The welding arm with the embedded welding head can be horizontal and up and down movement on the cross beam of the gantry frame, so that the welding nozzle on the head can be aligned to the welding seam. The equipment at the front end of the welding arm has a welding machine automatic tracking device, and then the gantry frame goes in a straight line on the rail, automatic welding. This machine is equipped with automatic welding, recycling and processing equipment.

2.Technical parameter
