Automation Items Customize Segment LCD Screen Display Module
7 segment lcd display :
| Name | | Automation Items Customize Segment LCD Screen Display Module | Accuracy | | 0.5%(default),0.2% | Data update rate | | 1s | Input | Current | Rated value:AC 1A,5A | Voltage | Rated value:AC 100V,220V,400V etc | Overload | Continuous:2 times of rated value | Frequency | 45~65Hz | Safe Power Supply | Range | AC 80~270V 50/60Hz,DC 100~350V | Consumption | ≤5VA | Digital Input | | 2 dry contact inputs,Isolation:2kVAC | Relay Output | | 2 relay outputs,contact rated at AC 5A/250V or DC 5A/30V,Isolation:2kVAC | Analog Output | | dc 4~20mA,load ≤350Ω DC 0~5V,load≥20kΩ | Communication Port | | RS485,Modbus-RTU,2-WIRE,up tp 9600bps | Degree of Protection | | Front:IP64,Rear :IP20 | Operating Temperature | | -40℃~70℃(LED),-25℃~70℃(LCD) | Storage Temperature | | -45℃~85℃(LED),-30℃~80℃(LCD) | Relative Humidity | | ≤93%RH | Insulation | | ≥2kVAC | Altitude | | ≤2500m |
|
F A Q:
Q1:How long is the warranty?
A:The warranty period is one year.During the warranty period, in
case of non-human injury, we will provide free repair or
replacement, including delivery costs.Beyond warranty: we provide
repair parts at a lower cost and provide services free of charge.
Q2:Do you accept customization?
A:Yes, we are glad to provide customized services.Our factory can
design and produce the appearance, logo, material, color,
size,installation method and so on according to customers'
requirements.
Q3:What are your payment terms?
A:Sample 100% TT,batch order 30% deposit, 70% balance before
delivery
Q4:How long is the delivery time?
A:For the finished products in stock, the delivery time is within
3-7 days;No inventory for 20-25 days;For customized samples and
bulk orders, the lead time is 7-30 days.
Q5:How can I get a sample?
A:Since most of our products are high value products, there are no
free samples.If you need to order a sample for inspection, we would
like you to pay the sample fee and freight, and the sample will be
sent to you upon receipt of payment.
