Graphic LCD Display Module, 128x64 Dots COB STN Gray LCD Module 12864 LCM

Graphic LCD Display Module, 128x64 Dots COB STN Gray LCD Module 12864 LCM

Graphic LCD Display Module 128x64 Dots Features:

Display format:128 x 64 dot-matrix; 1 / 64 duty

Display mode: STN/yellow-green/Transflective/positive

Structure: STN / FSTN LCD, Bezel, Zebra, Heat Seal and PCB

Controller:S6B0108

Module size:93.0(W) × 70.0(H) × 12.5 max (T) mm

Viewing area size: 73.2(W) × 39.2(H) mm

Dot size: 0.48(W) × 0.48(H) mm

Dot pitch: 0.52(W) × 0.52(H) mm

LCD Driving Voltage: 16.0V

Operating temperatures: -20 to 70°C

Storage temperatures: -30 to 80°C

Graphic LCD Display Module 128x64 Dots COB Applications

Digital products, POS machine, instrument & meter, automobile electronics, communication machine, medical machine, security machine, household electrical appliances and others

Frequently Asked Questions ( FAQ )

Q: How about the Delivery term of COG Graphic LCD Display Module?

A:For samples , we will finish production and ship within 7 working days .

We usually arrange DHL , UPS , FedEx express to ship samples .

For bulk orders , usually 30 working days and depends on your design .

We support shipping by air or by sea as per customers' requirements.

Q: What is your Packing term?

A: Protect product with polyfoam and multi layer paper board .

Special protect carton for exporting product .

Per customer requirement .

Q: Can you support OEM and ODM?

A:We support both standard and customized products and can put your logo on the products .

Our experienced R&D team will support technical questions . ODM and OEM products are warmly welcome .

Q:Why should a client choose your company?

A:We are specialized in offering top quality Mono and TFT LCD solutions.

More than 10 years’ experience in LCD R&D and manufacturing .

Strong R&D term supports perfect custom design services.

Small orders are accepted and welcome.

Graphic LCD Display Module 128x64 dots Mechanical Drawing

Wide Range of LCD Products For Various Applications To Choose From

Zopin Technology Co. Ltd is an innovative supplier of LCD display solutions. We focus on leading-edge LCD displays and electronic technologies for both existing and future markets.

Our main products are monochrome LCD Display with the mode of TN, HTN, STN, FSTN, DFSTN, VA, TFT LCD Display Module ranges from 1.44 to 21.5 inches, and touch panel solutions. They are widely used in digital products, POS machines, instruments and meters, automobile electronics, communication machines, medical machines, security machines and household electrical appliances.

High Quality ROHS Compliant Products

Zopin Technology is managed strictly complying to ISO 9001 and ISO 14001 standard. All of our LCD products are ROHS compliant. Moreover , we provide one-year warranty.

Supported By Engineers With 15 Years' Experience

Backed by strong R&D team with 15 years' experience and professional technicians, We have built long-term partnerships with some customers.

In addition, our responsible sales team has been dedicated to offering you timely delivery and best after-sale services.

Benefit From Our Advantages

1 . Segment LCD displays, character LCD modules, graphic LCD modules and TFT LCD modules are all available.

2 . Custom designs for COB, COG, COF, TAB LCD modules are highly welcomed.

3 . Available sizes of TFT LCD : 1.44, 1.7, 2.0, 2.4, 2.8, 3.2, 3.5, 3.97, 4.3, 5.0, 5.5, 5.6,5.7, 7.0, 8.0, 8.4, 8.9, 9.7, 10.1, 10.4, 11.6, 12.1, 13.3, 15.0, 15.6, 18.5 and 21.5 inch.

4 . Custom resistive and capacitive touch panels as well as super brightness backlights are also offered.

5 . The raspberry pi development boards and arduino controller boards supported.

6 . Offering original industrial Innolux, AUO, BOE, Tianma TFT LCD modules ( Grade A ).

7 . Customized adjustments and designs in functions and prices for LCD solutions and OEM products are accepted.

Contact Us Today

Your specific requirements and drawings are appreciated and welcomed, contact us immediately.
