Product Description:
DIN6926 Stainless Steel A2.70 Hex Flange Nylon Insert Lock Nuts
DIN6926 Stainless Steel A2.70 Hex Flange Nylon Insert Lock Nuts
Made In China.
The metric Nylon Insert Flange is a hex drive nut and washer
combination.
This product combines the best attributes of both common hex nylon
insert and flange type locknuts and requires sufficient thickness
to accommodate wrenching height and nylon collar height.It’s common
to find product with blue nylon rings,designating the part as
metric.
We offer low carbon steel, medium carbon steel, alloy steel,
stainless steel and brass, aluminum alloy Washers.
Flange nuts can be heated, oxidized black, galvanized, hot bucket
galvanized, black zinc, copper plating, nickel plating, chromium
plating, Dakota and other treatments to meet various corrosion
resistance or strength requirements.
Please state this requirement in your inquiry.
| Products name | DIN6926 Stainless Steel A2.70 Hex Flange Nylon Insert Lock Nuts |
| Standard: | DIN,ASTM/ANSI JIS EN ISO,AS,GB |
| Material | Carbon Steel:Q235,#45,65Mn,#70;Stainless Steel:SS304, SS316,SS316L |
| Steel Grade: Class 4,Class 8,Class 10 and Class 12 |
| Finishing | Black Oxide,HDG(Hot Dip Galvanized),,Yellow Zinc Plated,Blue White
Zinc Plated,Dacromet,PTFE |
|
| Related Products | ISO4017 Hex Bolts,ISO4032 Hex Nuts,ISO7089 Flat Washers |
| Application | The flange makes the Nylon insert flange lock nut ideal when
assembling components that consist of thin materials,slots or
non-precision oversize holes. Mating part must extend at least one thread past the flange nut top
surface to assure locking element engagement.The flange will
typically require more torque to produce a clamp load than
non-flange nuts. |
| Stock Products | Flange Lock nut in stock with Black Oxide,Zinc Plated,Yellow Zinc. |
| Get Free Samples for standard fastener from Jiangyin XiangGu
Hardware Products Co.,Ltd |
| Focus On Supplying High Quality Fasteners. |
Product Drawing:
| Metric Nylon-Insert Flange Locknuts |
| DIN 6926-1983 |
 |
| d | p | dc | h | m | s |
| max | min | max | min | min | max |
| M5 | 0.8 | 11.8 | 6.74 | 7.1 | 4.7 | 7.78 | 8 |
| M6 | 1 | 14.2 | 8.74 | 9.1 | 5.7 | 9.78 | 10 |
| M8 | 1/1.25 | 17.9 | 10.67 | 11.1 | 7.6 | 12.73 | 13 |
| M10 | 1/1.25/1.5 | 21.8 | 13.07 | 13.5 | 9.6 | 14.73 | 15 |
| M12 | 1.25/1.5/1.75 | 26 | 15.67 | 16.1 | 11.6 | 17.73 | 18 |
| M14 | 1.5/2 | 29.9 | 17.68 | 18.2 | 13.3 | 20.67 | 21 |
| M16 | 1.5/2 | 34.5 | 19.46 | 20.3 | 15.3 | 23.67 | 24 |
| M20 | 1.5/2.5 | 42.8 | 23.96 | 24.8 | 18.9 | 29.16 | 30 |
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory and OEM are available.
Q: How long is your delivery time?
A: Generally it is 2-5 days if the goods are in stock,or it is
15-30 days if the goods are not in stock, it is according to
quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay
the cost of freight.
Q: What is your terms of payment ?
A: 30% T/T in advance ,balance before shipment or L/C.
If you have another question, please feel free to contact us.
