    ф2mm ф8mm Nail Penetration Test Machine For Lithium Lead Acid Battery

    Ф2mm Ф8mm Nail Penetration Test Machine For Lithium Lead Acid Battery


    Battery Nail Penetrating Testing Machine


    Function

    Test safety capability of battery.

    Nail penetrates the specimen battery and check whether it will fire or explode

    Type

    Three tanks

    Weight

    180kg

    Internal space

    300mm*300mm*300mm

    Corresponding test standard

    SJ/T11170-1998

    UL2054:1997,

    GB/T18287-2000


    Description

    Using steel nail penetrating the battery, the tester is used to check safety capability of battery, and the battery is qualified without fire, and explosion.

    The nail penetrating test is processed under temperature of 20℃±5℃.

    The specimen battery has thermocouple whose contact spot is located on the largest surface.

    Place the battery on the fuming cupboard, using stainless nail with diameter of 2-8mm to penetrate the centre position of largest side of battery at speed of 10mm/s-40mm/s and keep for 5s.

    Test result: the battery is qualified without fire and explosion.


    Applicable objects


    Lithium battery, nickel battery, Ni-MH battery, lead-acid battery


    Specifications


    Model

    GX-5068

    Steel nail

    ф2mm—ф8mm high temperature resistant

    Space between battery surface and nail point

    150mm

    Penetrating speed

    10—40mm/s

    Penetrating force

    150~200KG

    Force display

    Pressure sensing and LED display

    Test stroke

    150mm

    Drive mode

    Cylinder drive

    Structure of tester

    Box-type to be explosion proof, fire proof, anti-corrosion and easy to clean

    Dimension of explosion proof tank

    450×750×550mm(W×H×D)

    Dimension of controller box

    300×260×170mm

    Power

    1ф220V , 50HZ
