NS5-SQ10-V2 NS5SQ10V2 OMRON Interactive Display HMI Operator Panel

    Buy cheap NS5-SQ10-V2 NS5SQ10V2 OMRON Interactive Display HMI Operator Panel from wholesalers

    Buy cheap NS5-SQ10-V2 NS5SQ10V2 OMRON Interactive Display HMI Operator Panel from wholesalers
    • Buy cheap NS5-SQ10-V2 NS5SQ10V2 OMRON Interactive Display HMI Operator Panel from wholesalers
    • Buy cheap NS5-SQ10-V2 NS5SQ10V2 OMRON Interactive Display HMI Operator Panel from wholesalers

    NS5-SQ10-V2 NS5SQ10V2 OMRON Interactive Display HMI Operator Panel

    Ask Lasest Price
    Brand Name : Omron
    Model Number : NS5-SQ10-V2
    Price : $50-500
    Payment Terms : T/T, western union
    Supply Ability : 10pc/per week
    • Product Details
    • Company Profile

    NS5-SQ10-V2 NS5SQ10V2 OMRON Interactive Display HMI Operator Panel

    NS5-SQ10-V2 NS5SQ10V2 OMRON Interactive Display HMI Operator Panel

    Tech Specifications


    Type

    Dedicated Standard Touch Screen Human Machine Interface (HMI)

    Industry Standards/Certifications

    UL, CSA, CE

    Display Type

    Thin Film Transistor (TFT) Color Graphics Liquid Crystal Display (LCD)

    Display Size

    5.7 in

    Accessories

    CXONE, CXONELT, NS-US22, NS-US52, NS-USBEXT-1M, XW2Z-S002, CS1W-CIF31, XW2Z-200T, XW2Z-500T, NS-AL002, HMC-EF183, HMC-EF283, HMC-EF583, CJ1W-CIF11, V520-RH21-6, C200H-CN229-EU, XW2Z-200T-2, XW2Z-500T-2

    Spare Parts

    CJ1W-BAT01, NT30-KBA01, NT30-KBA04, NT31C-KBA05, NT31C-KBA05N

    Interaction

    Touch Screen

    Touch Screen Type

    Matrix Resistive Membrane

    Libraries Available

    Smart Active Parts, Keyboards, Tenkeys, Screen Templates

    Programmable Logic Controller (PLC)/Device Compatibility

    Omron C/CVM1/CV/CS/CJ/CP/NJ Series, Mitsubishi A/FX/Q/QnA Series, Yokogawa FA-M3R Series, Siemens S7-300 Series, Rockwell SLC500/MicroLogix/ControlLogix/CompactLogix/PLC-5, Trajexia, Yaskawa MP900/MP2000/F7 Series, 3G3MV, 3G3JV, EJ1, E5ZN, E5AR, E5ER, E5AN/-H, E5EN/-H, E5CN/-H, E5GN, PictBridge-compatible printer via USB

    RS-232C Port

    2 Built-In

    Universal Serial Bus (USB) Host

    1 Built-In

    Universal Serial Bus (USB) Slave

    1 Built-In

    Printer

    PictBridge

    Hazardous Location

    Class 1 Division 2

    Enclosure Type

    Type 1, 4X indoor use only

    Maritime Standards

    ABS, NK, LR, DNV, RINA, BV, GL, KR, CR, GOST-R, EAC

    Memory Card Type

    Compact Flash

    Mounting Orientation

    Landscape

    Bezel Color

    Ivory

    Ladder Monitor

    Yes

    BMP-JPG Image Data

    4096

    Display Colors

    256

    Direct Current (DC) Supply Voltage

    24 V

    Depth

    54.8 mm

    Height

    142 mm

    Width

    195 mm

    Memory Size

    60 MB

    Effective Display Area Width

    117.2 mm

    Effective Display Area Height

    88.4 mm

    Resolution

    320 x 24


    FAQ:


    Question:Which software Omron NS5 series HMI use for programming?


    Answer:CX-One software allows users to build, configure and program a host of devices such as PLCs, HMIs and motion-control systems and networks using just one software package with one installation and license number. This greatly reduces the complexity of the configuration and allows automation systems to be programmed or configured with minimal training.


    Question: What is the dimension of NS5-SQ10-V2 Omron NS5-SQ10-V2 Touch Panel??


    Answer:The dimension of NS5-SQ10-V2 Omron NS5 HMI is 5.7 inch ,which is 148mm long and 118mm wide.
