    High Precision Rotary Hydraulic Collet Chuck For Laser Cutting CNC Machine

    Ask Lasest Price
    Brand Name : Lingman
    Model Number : JAB-60
    Price : USD 480-950/set
    Payment Terms : T/T, L/C
    Supply Ability : 100 sets per month
    Delivery Time : 15-20 work days
    • Product Details
    • Company Profile

    High Precision Rotary Hydraulic Collet Chuck For Laser Cutting CNC Machine

    High Precision Rotary Hydraulic Collet Chuck For Laser Cutting CNC Machine

    1. Description

    This hydraulic collet chuck can be used for internal expansion and external clamping. Its construction is of integral heat-treated steel. The bearing has no load, the chuck has good high-speed performance and long service life. Still cold when spinning. Forced opening of the collet is a two-way power. When the pressure is interrupted, the chuck locks itself and remains clamped.

    Installation is simple and convenient, just connect the flange directly to the spindle. It can be connected to the machine system through a three-point combination valve. The collet does not retract and can be controlled normally. The body length accuracy is within 0.01mm. It is an ideal power source for pull-back power chucks and simple clips, and can also be used as a power source for other devices.



    2. Performance Parameters

    • Model number
    JAB-60
    • Push side
    225.8cm²
    • Pull side
    198.9cm²
    • Working pressure
    0.4-0.7MPa
    • Limit speed
    3000r/min
    • Step hole
    62mm
    • Through hole
    56mm
    • Max. clamping force
    7.8/7.2
    • Connecting bolt
    4-M10
    • Adapter collet
    20C
    • Collet fixing screw
    2-M5


    ​ 3. Dimensions


    SpecificationsABCDEFGHIL
    JAB-60218170621759456511198125


    4. Advantages

    a. Full stroke design
    b. Wide range of applications, diversification of processing profiles
    c. High repetitive positioning accuracy
    d. Low maintenance cost, long service life

    e. Multiple configurations are available
    e.1 Solid or hollow

    e.2 Comb-type or mortise-groove type claws


    5. Our Service

    a. We are the direct factory with good price and fast lead time.
    b. Professional design team work with you.
    c. Professional QC team to guarantee the high quality.
    d. Providing OEM & ODM service.

    6. Production Line
