    CE SUS304 V Type Powder Mixing Machine Mirror Polished Detergent Powder Mixer

    Ask Lasest Price
    Brand Name : WKS
    Model Number : WKS-V-1
    Certification : CE Certificate
    Price : negotiable
    Payment Terms : T/T
    Supply Ability : 10 sets for month
    Delivery Time : about 30 working days
    • Product Details
    • Company Profile

    CE SUS304 V Type Powder Mixing Machine Mirror Polished Detergent Powder Mixer

    Large Quantity V Type Powder Mixing Machine Detergent Powder Mixer


    V Type Powder Mixer


    Products Description:

    V series mixer is a mixing equipment for pharmaceutical industry and other powder and granular materials. It is widely used in pharmaceutical, food, chemical, and other industries. The equipment is designed based on the advantages of similar foreign products. Because the lengths of the two cylindrical columns that make up the mixer are not equal, they form an asymmetry. When the mixer is running, the materials are different from the decomposition and combination angles, forming an axial layer by layer Alternate diffusion and mixing, due to the different planes of the materials on the inner wall of the cylinder, also have different potential energy between each other, resulting in lateral convection mixing. The above-mentioned mixing effect is continuously repeated, so that the materials reach a very uniform random mixing state. Due to the internal gravity mixing, this machine has a small pressure feed to the material, high mixing uniformity, and is made of stainless steel material. The inner and outer walls are polished, and the power consumption and efficiency are high. It is an ideal device for the new generation of powder mixing.
    The V type mixer adopts manual feed and closed disc valve discharge, which can avoid dust spilling; with unique mixing barrel structure, high efficiency blending and no dead angle, the materials can mix evenly. The inside and outside of the machine are polished. It is suitable for smaller powder, blocks and the material that contain a certain mixture of water. In addition, the machine is also equipped with a timing device; In that case, you can control the material mixing time.

    Technical parameter

    TYPEFULL VOL.
    (m³)
    LOADING
    RATIO
    L
    (mm)
    W
    (mm)
    H
    (mm)
    DISCHARGE DIAMETER
    (mm)
    ROTATING HEIGHT
    (mm)
    ROTATING SPEED
    (rpm)
    ELECTRIC POWER
    (kW)
    WEIGHT
    (kg)
    WKS-V-0.10.10.4~0.816505001550φ801600120.75~1.1180
    WKS-V-0.30.30.4~0.819006001750φ1001900121.1~1.5350
    WKS-V-0.50.50.4~0.823007002100φ150225091.5~2.2550
    WKS-V-110.4~0.8270010002500φ150270092.2~41000
    WKS-V-1.51.50.4~0.8300010002600φ200290084~5.51100
    WKS-V-220.4~0.8320012003100φ200325084~7.51500
    WKS-V-2.52.50.4~0.8395015003550φ200380075.5~111700
    WKS-V-330.4~0.8410015003600φ200385067.5~111800

    Main Features:
    1. Mirror polished of inner and outer shell to meet cGMP standard.
    2. No blind angle in the V-shells, no accumulation of materials, high speed I-bar, efficient and short mixing time.
    3. Mixing uniformity can reach 99%
    4. Rotating valve is equipped for discharging
    5. Fully integrated motors and controls
    6. Can work with vacuum feeding system to create dust-free working condition.

    Pictures


    Packaging

    All products sold by our company will be safely packed according to the size and weight of the product.


    Delivery

    Usually, we ship your cargo by FedEx, DHL, UPS or any other logistic company.
    You can also use your own shipping agent.


    Logistics
    1. DHL, UPS, FedEx, EMS, TNT, ARAMEX and etc. We will choose the most economical one for you or designate a specific one by yourself.
    2. Tracking number will be sent to you within 2 or 3 days after delivery.

    Feedbacks
    We value any comments, suggestions from you. If you got any problem, please contact us


    Delivery Problems
    If you find damage or shortage of goods, please take some meaningful photos for a witness and send it to us, we'll solve it within 24 hours.

    Warranty
    Typically every product got 1 year of warranty, we'll do whatever we can to assist you to solve the issue.
