1. Extruder: 1 set
(1) Screw diameter: 90mm, Rotation speed of screw: 0～72rpm.
(2) L:D: 33:1, Material of screw: 38CrMoALA ,
the screw is suitable for PP+PE Virgin.
(3) Filter: Auto screen changer.
(4) Pressure feedback system can adjust the screw speed
automatically.
(5) Material of barrel heater: Far infraed
(6) Metering pump, rotation speed: 0-45 rotation.
(7) Electrical heating round spinneret: 1 set
(8) Spinneret heater: by ceramic heating rings with SS insulating
layer.
(9) Spinneret plate: 2 pieces
2. Quenching tank: 1 set
(1) The tank is made by SS 304.
(2) Pushed and pulled in side way, the automatic lifting of tank.
(3) Special designed roller guider to separate the yarn in the tank
easily.
3. Dryer:1 set
4. Frist Seven roller stretching unit
(1) Five variable diameter rollers and two steel rollers.
(2) Max drafting force: 1000 daN.
(3) Steel box with accurately grind gear makes the rollers run
smoothly.
(4) Built-out oil lubrication system which makes the gears runs
steady.
The bearings are from TIMKEN-TWB.
5. Double layers hot blast stretching oven: 1 set
(1) Heating power: 23KW
(2) Oven length: 5000 mm
(3) Special design of hot air channel which make the temperature
evenly.
6. Second Seven roller stretching unit
(1) Seven variable diameter rollers with hard chrome plating.
(2) Steel box with accurately grind gear makes the rollers run
smoothly.
(3) Built-in oil lubrication system which makes the gears runs
steady.
7. Spool winder or ring twisting winder
(1) Bobbin size as client's reqeust.
8. Actual running power: 115KW
