    IP 20 Temperature Control Microwave Motion Sensor With Automatic Switch For Lights

    Ask Lasest Price
    Brand Name : HAISEN
    Model Number : HD011S
    Certification : ROHS, CE TUV RED
    Price : Negotiation
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 100000pcs per month
    Delivery Time : 1-3 days for sample order, 1-2 weeks for bulk order
    • Product Details
    • Company Profile

    IP 20 Temperature Control Microwave Motion Sensor With Automatic Switch For Lights

    IP 20 Temperature Control Microwave Motion Sensor With Automatic Switch For Lights


    Features:

    • HD011S On/Off Control.
    • Microwave Mition Sensor.
    • Columnar Antenna size of 76.9*39.9*27.7mm.
    • Unique design with loop in and loop out, easy to instal.Detection area, hold time and daylight sensor are selectable via DIP switch.
    • 5.8GHz high frequency microwave.
    • 4-pole press-in terminal (L, N,N,L′),easy assembly.
    • Detection area, time delay and daylight threshold can be precisely set via DIP switch.

    Detailed Product Description

    InputVoltage Range220~240 VAC 50/60Hz
    OutputLoad TypeMax.100W
    Stand-by Power≤0.5W
    Sensor ParametersHold time5s/60s/3min/10min
    Detection Area50%/100%
    Daylight Sensor30Lux/Disable
    ModeConstant on mode/Sensor mode
    Mounting HeightCeiling mounting 3-6m
    Sensing AreaMax12m
    Wireless ParametersOperating Frequency5.8 GHz ±75 MHz
    Dimming Control0N/0FF
    Operating EnvironmentOperating Temperature-25°C~+60°C
    Safety & EMCCertificate RequirementROHS, CE TUV RED
    OthersWiring Method4-pole pluggable clamp terminal(L,N,N,L’) for 0.75-1.5mm 2 cable
    IP RatingIP20
    Installation Size76.9*39.9*27.7mm
    Packaging RequirementBubble pack, paper flat, outer carton.
    Life50000h

    Wiring diagram


    Mechanical structure(mm)


    DIP Switch Setting


    Detection coverage


    Demo


    Application


    widely applicated in corridor , fire exit ,warehouse , base - ment and other indoor lighting places .


    HD011S.pdf
