    TS16949 Air Spring 93029 Standard Code Model Number 16 Max OD 153Mm

    Ask Lasest Price
    Brand Name : AIRSUSTECH
    Model Number : 1B13070
    Certification : ISO/TS16949:2009
    Payment Terms : T/T, Western Union,Paypal or Others
    Supply Ability : 1000pcs/week
    Delivery Time : 3-8 Working Days
    • Product Details
    • Company Profile

    TS16949 Air Spring 93029 Standard Code Model Number 16 Max OD 153Mm

    Air Spring 93029 Standard Code Model Number 16 Max OD 153 mm


    AIRSUSTECH 1B13070 can replace Air Spring 93029 Standard Code Model Number 16 product description:


    The air spring shock absorber AIRSUSTECH 1B13070 can replace Air Spring 93029 Standard Code Model Number 16 can only push the bellows towards the workpiece, otherwise it must be equipped with a stroke limiter at the end of the stroke, otherwise the bellows will be overloaded

    • In order to press the air spring shock absorber AIRSUSTECH 1B13070 can replace Air Spring 93029 Standard Code Model Number 16 to the minimum height, a restoring force is required. Usually, this is achieved by applying a load

    • The entire bearing surface of the upper and lower plates of the air spring shock absorber AIRSUSTECH 1B13070 can replace Air Spring 93029 Standard Code Model Number 16 must be used to absorb the force

    • Before disassembling the air spring shock absorber AIRSUSTECH 1B13070 can replace Air Spring 93029 Standard Code Model Number 16 , the internal air must be released to prevent accidents and personal injury.

    • During operation, the rubber air spring shock absorber AIRSUSTECH 1B13070 can replace Air Spring 93029 Standard Code Model Number 16 shall not be in contact with other parts


    1B13070 Technical Parameters
    Top Cover Plate Diameter114.5 MM
    Bottom Cover Plate Diameter114.5 MM
    Screw Center Distance44.5MM
    Distance Gas Hole Between Nut22.25MM
    Gas Hole1/4NPTF
    Top Screw (Nut) Tooth

    2pcsX3/8” - 16 UNC


    Bottom Screw (Nut) Tooth

    2pcsX3/8” - 16 UNC


    Rubber Bellows DiameterNatural Φ145MM
    The HeightNatural 90 MM
    ConnectionP1
    Max OD153 MM
    Min. Height46 MM
    Max. Height91 MM

    AIRSUSTECH 1B13070 Cross OEM Original Equipment Manufacturer:


    AIRSUSTECH Part Number:1B13070

    AIRSUSTECH Bellow Number:1B-16

    AIRSUSTECH Bellow Number:1B 16

    ​AIRSUSTECH Bellow Number:1B16

    Air Spring Standard Code 93029

    Model 16

    Torpress Model 16

    Connection P1

    Technical performance parameter list of AIRSUSTECH 1B13070 air spring:
    Bearing
    load
    Power
    (kg)
    Inflation pressure0.2MPa0.3MPa0.4MPa0.5MPa0.6MPa0.7MPa0.8MPa0.7MPa
    Volume(dm³)
    Installation height
    50(mm)1572192863764505236110.24
    60(mm)1221832523284044725450.37
    70(mm)1071702383043774395010.46
    80(mm)1001532032643233784320.52
    90(mm)731121602092603003340.58
    Stiffness and frequency at design heightVertical stiffness(Kg/cm)6089119148181189208
    Stiffness and frequency at design heightNatural frequency Hz1.231.191.171.151.141.081.06
    Stiffness and frequency at design heightNatural frequency cpm74717069686564
