    C/W API SL225 Forging Drilling Rig Swivel 5000psi

    Ask Lasest Price
    Brand Name : FORUS
    Model Number : Sl225
    Certification : API
    Payment Terms : L/C, T/T, Western Union
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    C/W API SL225 Forging Drilling Rig Swivel 5000psi

    Drilling Rig Components SL225 Swivel For Oil Drilling


    Product Description


    1. Swivel C/W API Standard lifting ring and PIN-PIN joint.


    2. The type of washing pipe packing assembly is box, and they can change quickly on the drilling table without unloading swivel and gooseneck.


    3. The drilling hole which is on the top of gooseneck provided the way for the well ropes of testing well


    4. C/W API 4″joint of swivel belts.


    5. Drilling Swivel conform to API 8CPSL1, Allow to use API monogram.


    MODELSL70SL110SL135SL160SL225XSL225XSL450
    Max. static load (Ibf)15174025290303492359695058205058201011640
    Working load of main bearing (Ibf)67440101164224808269770337213377213562022
    Gooseneck pipe thread2 3/8" TBG4 1/2" NPT4 1/2" TBG4 1/2" TBG4 1/2" TBG4" NPT4"NPT
    Bottom thread of central pipe joint2 7/8" UP DP4 1/2" REG LH5 1/2" REG LH5 1/2" REG LH6 5/8 REG LH6 5/8 REG LH6 5/8"REG LH
    Max. working pressure (psi)2143300050005000500050005000
    Opening diameter of central pipe (in)1.962.52.992.992.992.992.99
    Overall dimension (ft)5.57×1.49×0.985.53×0.93×1.677.41×2.21×2.447.87×2.33×2.478.53×2.56×2.609.45x3.37x3.499.89×3.59×3.49
    Mass (Ib)60674117112176292556666746
