    Copper 4 Way Reversing Valve for Heat Pump Systems

    Ask Lasest Price
    Brand Name : SANHUA
    Model Number : SHF Series
    Certification : CQC
    Price : negotiate
    Payment Terms : T/T
    Supply Ability : 2000pcs per weeks
    Delivery Time : 4-6 weeks
    • Product Details
    • Company Profile

    Copper 4 Way Reversing Valve for Heat Pump Systems


    4 way reversing valve


    Four-way reversing valves are applicable for heat pump systems such as central, unitary and room air conditioners to realize switching between cooling mode and heating mode by changing the flow path of refrigerant.


    Features


    * Wide application range .

    * Suitable for cooling capacities from 3.6 to 420KW (R410a, contion 2).

    * Several designs available.


    General Specifications


    * Applicable for all common HCFC, HFC refrigerants such as: R22, R134a, R404A, R407C, R410A, R507

    * Ambient temperature min./max.: -30°C / +55°C

    * Relative humidity: 0 to 95% RH • Max. operating pressure: 4.2MPa (42 bar)

    * Installation position: - Coil upwards or with body axis in horizontal alignment - Flow direction according to installation instruction

    * Certifications: UL/CSA and declaration according to LVD or PED


    Valve seriesValve modelFixed/ Inverter ACConnections ODFOPDMedium Temp
    ØDØE/S/CMax.Min.
    InchInchMpaMpa
    SHF 4SHF-4H-23U-PGeneral5/163/83.10.1-30/+120
    SHF 7SHF-7H-34U-PGeneral3/83/83.10.1-30/+120
    SHF 9SHF-9H-35U-PGeneral3/85/83.10.1-30/+120
    SHF 11SHF-11H-45D1General3/85/83.10.1-30/+120
    SHF 14SHF-14A-46General1/23/43.10.3-30/+120
    SHF 20SHF-20D-46-01Fixed1/23/43.10.3-30/+120
    SHF 20SHF-20D-46-02Inverter1/23/43.10.3-30/+120
    SHF 20SHF-20D-46-03Fixed1/23/43.10.3-30/+120
    SHF 20SHF-20D-46-04Inverter1/23/43.10.3-30/+120
    SHF 35SHF-35B-67-01Fixed3/47/83.10.3-30/+120
    SHF 35SHF-35B-67-04Inverter3/47/83.10.3-30/+120
    SHF 35SHF-35B-67-05Fixed3/47/83.10.3-30/+120
    SHF 35SHF-35B-67-06Inverter3/47/83.10.3-30/+120
    SHF 50SHF-50-79-03Fixed7/81 1/83.10.3-30/+120
    SHF 50SHF-50-79-04Inverter7/81 1/83.10.3-30/+120
    SHF 70SHF(L)-70-810-10Fixed11 1/43.10.3-30/+120
    SHF 100SHF(L)-70-810-20Inverter11 1/43.10.3-30/+120
    SHF 100SHF(L)-100-1012General1 1/41 1/23.10.3-30/+120
    SHF 140SHF(L)-140-1214General1 1/21 3/43.10.3-30/+120
    SHF 175SHF(L)-175-1217General1 1/22 1/83.10.3-30/+120
    SHF 210SHF(L)-210-1321General1 5/82 5/83.10.3-30/+120
    SHF 350SHF(L)-350-1721General2 1/82 5/83.10.3-30/+120
    SHF 420SHF(L)-1420-2125General2 5/83 1/83.10.3-30/+120

    Nominal Operating Conditions


    Nominal Operating ConditionsCondition 1Condition 2
    Condensing Temperature tc38°C54.4°C
    Evaporating Temperature to5°C7.2°C
    Superheat Δtsh5K5K
    Subcooling Δtsc0K5K

    Should you have any question, feel free to contact.
