    Ring Lug NTC Temperature Sensor 10KOhm 3984 For Battery Management System

    Ask Lasest Price
    Brand Name : AMPFORT
    Model Number : CWF103F3984FB150RC
    Certification : ROHS
    Price : 0.4USD/PC
    Payment Terms : TT IN ADVANCE
    Supply Ability : 100,000,000PCS PER WEEK
    Delivery Time : 10 workdays
    • Product Details
    • Company Profile

    Ring Lug NTC Temperature Sensor 10KOhm 3984 For Battery Management System


    Standard NTC Thermistor Ring Lug Temperature Sensors 10KOhm 3984 For Battery Management Systems


    Description Of The Ring Lug Temperature Sensors


    High stability lug temperature sensors is suitable for surface temperature sensing applications, especially when a high electrical insulation (rated to 2.7 kVAC) and good thermal contact with the surface is required. These sensors provide accurate and dependable surface temperature measurement across a wide temperature range and are designed for long-term, stable operation at a peak temperature of 150°C. The CWF103F3984FB150RC lug sensors incorporate a negative temperature coefficient (NTC) thermistor with two multi-stranded AWG26, 600 V rated, ETFE insulated, silver-plated copper wires mounted inside the barrel of a lug terminal. Mounting of the CWF103F3984FB150RC lug sensor can be accomplished by use of a M3.5 (#5 or #6) screw. The CWF103F3984FB150RC series meet both AEC-Q200 qualified and UL recognized. In addition to the off-the-shelf version, the CWF103F3984FB150RC series provides the designer with flexibility through electrical and mechanical customization options including an option for a 150°C rated automotive connector.


    Features Of The Ring Lug Temperature Sensors


    • Wide temperature range from -40°C to 150°C
    • Long term stability at peak temperature of 150°C (5000 h dry heat)
    • Resistance value of 10 KΩ at 25°C with tolerance down to ±1%
    • Minimum electrical breakdown voltage rating of 2.7 kVAC (3 second)
    • ETFE insulated cable: 150°C, 600 V rating (test voltage 3.4 kVAC)
    • Customization available upon request

    • Quick response
    • Rugged construction and easy mounting


    Application Of The Ring Lug Temperature Sensors


    Suitable for surface sensing applications, especially when a good electrical insulation and a good thermal contact with the chassis is required for:

    • Battery management systems
    • Power electronics
    • Heatsink thermal management
    • Automotive systems
    • Industrial equipment
    • Test and measurement systems
    • HVAC systems
    • Consumer appliances


    Mounting Of The Ring Lug Temperature Sensors


    • By means of M3 (stud #3, #4) or M3,5 (stud #5, #6) screw.Leads to be soldered or crimped
    • The device is suitable for screwing e.g. on metal surface
    • The leads are suitable for soldering e.g. on PCB
    • Consult Vishay for other cable length, cable section,screw sizes, insulation, connector crimping or other features


    Parameters Of The Ring Lug Temperature Sensors


    NameNTC Temperature Sensor
    P/NCWF103F3984FB150RC
    Resistance value at 25 °C10K Ohm
    Tolerance on R25-value±1%
    B25/85-value3984K
    Operating temperature range
    at zero dissipation
    -40°C to 150°C
    Weight2.0-3.2 g
    Min. insulation resistance between
    terminals and lug at 500 VDC
    100 MOhm
    Min. dielectric withstanding
    voltage between terminals
    and lug
    2700VAC
    150 °C long term stability5000 h dry heat
