2tons Fast Self Erecting Tower Crane Mini Load Automatic Assembly
Crane tower
General Introduction of this Self Erecting tower crane
Fast-erecting cranes are transported on the road as complete units
ready for use.
Thanks to their short wheelbase and compact slewing platform
design, they can be maneuvered easily on tight construction sites.
The benefits of fast-erecting cranes include the rapid erection and
versatility in use.
This means that these cranes can be used to build detached and
multi-occupancy houses as well as small infrastructure projects.
The flexible tower crane refers to the installation, erection, or
disassembly and transshipment very conveniently. The loading and
dismantling process can be carried out by its own mechanism without
the use of an external crane type, which can be completed in 1~2
hours or so
It is suitable for the construction of low and single building. It
has the characteristics of loading, erection, safety, shortcut,
high efficiency, low cost and little damage to the site.
Specification of this Self Erecting tower crane
| Specification | Unit | YT2527-20 |
| Max. height | m | 25 |
| Max.load | t | 2 |
| Working range | m | 6-27 |
Hoisting parameters | Max.hoisting height | m | 25 |
| Max.working radius | m | 27 |
| Max.hoisting weight | Kg | 2000 |
| Hoisting speed | m/min | 13/26 |
| Trolleying speed | m/min | 20/40 |
| Slewing speed | r/min | 0.25/0.8 |
| Erecting time | min | 10 |
| Outrigger span | m | 4.2x4.2 |
| Dead weight | Kg | 26000 |
| Travel parameters | Max.towing speed | Km/h | 15 |
| Hydraulic system | Hydraulic system | Mpa | 28 |
| Power supply | Rated Power | Kw | 23.1 |
Features
1. High performance, simplicity and stability
2. Good adaptability of the site
3. Low cost with power operation, Safe & environment protecting,
Low noise
4. Remote control with variable speed driving
5. Multilayer safety protection to guarantee the safety and
Reliability
6. Quick extension arm, no preset foundation and professional
installation.
Service
1. All the machines will be full tested before shipment
2. The total machine guarantee is 12 moths
3. 24 Hours technical support, email, telephone or video online
4. User-friendly english manual for machine using and maintaining
5. Sereral sets wearing parts will be free for you
Loading of this erecting tower crane
