EDP 352PPI Desktop PC LCD Module BOE 12.5Inch 3840×2160 400CD/M2 40PIN

    Buy cheap EDP 352PPI Desktop PC LCD Module BOE 12.5Inch 3840×2160 400CD/M2 40PIN from wholesalers

    Buy cheap EDP 352PPI Desktop PC LCD Module BOE 12.5Inch 3840×2160 400CD/M2 40PIN from wholesalers
    • Buy cheap EDP 352PPI Desktop PC LCD Module BOE 12.5Inch 3840×2160 400CD/M2 40PIN from wholesalers
    • Buy cheap EDP 352PPI Desktop PC LCD Module BOE 12.5Inch 3840×2160 400CD/M2 40PIN from wholesalers

    EDP 352PPI Desktop PC LCD Module BOE 12.5Inch 3840×2160 400CD/M2 40PIN

    Ask Lasest Price
    Brand Name : BOE
    Model Number : NV125QUM-N81
    Certification : Rohs,CE,FCC
    Price : Negotiation
    Payment Terms : T/T,W, Western Union, MoneyGram
    Supply Ability : 3000pcs per week
    Delivery Time : 4-5 working day
    • Product Details
    • Company Profile

    EDP 352PPI Desktop PC LCD Module BOE 12.5Inch 3840×2160 400CD/M2 40PIN

    eDP 352PPI Desktop Monitor Module BOE 12.5Inch NV125QUM-N81 3840×2160 400CD/M2 40PIN


    The NV125QUM-N81 is a 12.5 inch diagonal a-Si TFT-LCD display panel product from BOE Technology Group Co., Ltd. (hereafter called BOE), with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C , and the maximal vibration level of 1.5G (14.7 m/s²). It's general features are summarized by Eink in the following: Adobe RGB, sRGB, WLED Backlight, With LED Driver, Reverse I/F, Matte , eDP1.3. Based on its features, Einklcd recommend that this model be applied to Laptop, Pad & Tablet etc. According to the information stored in einklcd this model mass production on Q4, 2016, Now this model is discontinued. There are 8 items stock and 10 suppliers of this model on Panelook. We inputted this model's specification on Mar 10 2016 for the first time, and the latest update on Dec 27 2021. If you want to embed NV125QUM-N81 LCM in your future product, einklcd strongly recommend that you should contact with BOE or it's agent to learn lateast production and specification detail. The NV125QUM-N81 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.



    Panel BrandBOEPanel ModelNV125QUM-N81
    Panel Size12.5"Panel Typea-Si TFT-LCD , LCM
    Resolution3840(RGB)×2160, UHD, 352PPIPixel FormatRGB Vertical Stripe
    Display Area276.48(W)×155.52(H) mmBezel Opening-
    Outline Size282.08(W)×168.89(H) ×4.6(D) mmSurfaceAntiglare
    Brightness400 cd/m² (Typ.)Contrast Ratio1500:1 (Typ.) (TM)
    Viewing Angle85/85/85/85 (Typ.)(CR≥10)Display ModeHADS, Normally Black, Transmissive
    Best View onSymmetryResponse Time35 (Typ.)(Tr+Td)
    Display Colors16.7M 100% Adobe RGBLamp Type8S8P WLED , 15K hours , With LED Driver
    Frequency60HzTouch ScreenWithout
    Shape StyleSlim (PCBA Bent, T≤3.0mm)Application
      Signal InterfaceeDP (4 Lanes) , eDP1.3 , HBR2 (5.4G/lane) , 40 pins Connector
      Input Voltage3.3V (Typ.)
      EnvironmentOperating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
