Single Phase 20 Digit Smart Micro Grid System Solar Powered Meter
20 Digit Single Phase Smart solar power electric meter
Photovoltaic (PV) power generation is growing fastly in the South
Asia and Africa, As mini grid to effectively provide electricity
for the remote area which the utility grid cannot cover. The CA168
is special designed for PV solar generation mini grid to
measurement the power consumption, it can support 5A, 16A, 40A, 60
A current, 230V Nominal voltage, Class 1 accuracy class make sure
the good measurement. We have built in a RF module in the meter so
that the monitoring and management system can be developed, the
meter send the data to the data concentrator by RF, and then the
data concentrator upload the data by GPRS. The repeater can extend
the communication range for data concentrator.
Major Features
20 digit (Standard Transfer Specification) STS encryption
Detection of significant reverse energy (SRE)
IEC62056-21 compliant port allowing for easy data interrogation
Disconnects on overload and no credit
Dual power source working on both prepaid and credit mode
Programmable load limit and low credit warning
Detection and record tamper event such as cover open, reversal,
black-out, etc.
Easy access to 12 months historical consumption data and last 5
token entered
Utility benefit
Easy connection to User Interface Unit (UIU) for split type
applications
RF / GPRS wireless communication with a head-end AMR/AMI server
Time of Use (TOU), multi-tariff, holiday setting.
Advanced load control and disconnection features
Specifications:
Nominal voltage Un | 220/230/240 V |
Limited voltage | 70%~120%Un |
Nominal frequency fn | 50-60Hz+5% |
Basic current(Ib) | 5-10A |
Maximum current(Imax) | 60-100A |
Starting current(Ist) | 20mA |
Active energy constant | 1000imp/kWh |
Accuracy as Active energy to IEC62053‐21 | Class1.0 |
Power consumption in Voltage circuit | <2W <8VA |
Power consumption in current circuit | <1VA |
Operating temperature | 25℃ to+70℃ |
Storage temperature | 40℃ to+85℃ |
Insulation level | 4kV rms for 1min |
Impulse voltage withstand | 8kV, 1.2/50 μs |
Air discharge | 16kV |
Immunity to HF fields |
|
80MHz to 2GHz with load | 10V/m |
100kHz to 1GHz without load | 30V/m |
Fast transient burst test | 4kV |
Meter shell Protection Rate | IP54(IEC60529) |
Insulation System Classification | Protective Class II |
