Car Diagnostic Tester Original Upgraded SDT206 Car Smoke Leak
Detector Pipe EVAP Vacuum Leakage Diagnostic Tool EVAP Pipe Leakage
Analyzer 12V
Car Diagnostic Tester Car Smoke Leak Detector Main Unit Structure :
Car Diagnostic Tester Car Smoke Leak Detector Description:
AUTOOL Upgraded SDT 206 Car Smoke Leak Detector is a professional
auto pipe leak detect tool. It will help us position cars
motorcycles leakage on the pipe systems quickly and exactly, such
as
Intake System Test, Exhaust Systems Test, Crankcase system test,Car
Sealing Test, Fuel Tank System Test, Turbo System Test,Various Pipe
Fittings Test.
How to do leakage test?
1. Fill 20ml baby oil to the detector for the first time. Open the
engine cover, and hang the detector in the cover.
2. Disconnect the pipe that needs to be connected with detector.
3. Connect detector with DC12V battery, turn on the power switch,
and the detector starts to work.
4. In about 30 seconds, the pipe will be filled with smoke. Check
the leak points. Please use head lamp if necessary.
Car Diagnostic Tester Car Smoke Leak Detector Features:
1.[Wide Range of Applications]: For detecting the leakage of pipe
systems on cars, motorcycles, snowmobiles, off-road vehicles, ATVs,
light trucks and speedboats boats. Suitable for all car models.
2.[Powerful and Easy to Operate] : The AUTOOL SDT 206 has its own
Air Pump without relying on other machines and Pressure Gauge with
precise scales. Simply connect the detector with the DC12V battery,
it can output thick smoke within 30s after turning on.
3.[Advanced Technology]: It works on the EVAP system. (Provided
with another version that specially designed for EVAP system).
Equipped with dual flow meters for accurate data display &
Independently controlled Air mode and Smoke mode.
4.[Overheat & Anti-frost Protection]: This smoke detector has an
intelligent protector, if it exceeds the working limit, such as
over 75 ℃, it will automatically turn off the power to secure the
safety of both the operator and device.
5.[3 Years Warranty]: For damage caused by non-human factors, we
promise to resend parts for free within 3 years. For any needs, you
are warmly welcomed to contact us and we will get back to you ASAP
within 24 hours.
Car Diagnostic Tester Car Smoke Leak Detector Caution:
1.When you use this AUTOOL SDT 206 Car Smoke Leak Detector for the
first time, fill with 20ml oil . Please be careful NOT to beyond
this range.
2.The testing liquid : both liquid paraffin and baby oil are OK.
3.Fresh oil can be filled with only when the smoke gets thin, and
it can’t be filled over 20ml each time.
4.Before filling fresh oil, please pour out the left oil in the
detector & replace the detector oil regularly.
5.During the process of leak detection, please keep away from
smoke-sensitive parts.
6.Do NOT run the detector over 8 minutes continuously. It needs
interval rest.
7.The detector has an intelligent protector, if it exceeds the
working limit, such as over 75 ℃, it will automatically turn off
the power. In this case, please operate it later.
8.The round part of this detector has temperature, please be
careful to avoid burns.
9.If the test pipe needs to be disconnected in the middle, please
secure the other side with a rubber stopple.
Car Diagnostic Tester Car Smoke Leak Detector Packing List:
1pc * AUTOOL SDT 206 Car Smoke Leak Detector Main Unit
1pc * Hook (with hand-tighten nuts)
1pc * Rubber Connect Parts
1sets * Hard Rubber Hose Plug (with serial specification)
1sets * Soft Rubber Hose Plug (with serial specification)
1pc * Standard Cone Adapter
1pc * Universal Airbag Adapter
1pc * Power Cord Clamp
1pc * Valve Core Wrench
1pc * Test Oil Refill Bottle(oil not included)
1pc * EVAP Special Connector
1pc * Smoke Hose
1pc * User Manual
